МОТОРНОЕ МАСЛО, рис. 5,6,7,8
Проверка уровня моторного масла
Проверяйте уровень моторного масла спус-
тя несколько (около 5) минут после останов-
ки двигателя, при этом автомобиль должен
стоять на ровной горизонтальной площадке.
Извлеките щуп для измерения уровня мотор-
ного масла A (маслоизмерительный щуп),
очистите его, затем вставьте обратно до упора,
извлеките и проверьте, что уровень масла на-
ходится между метками "MIN" и "MAX". Рассто-
яние между метками "MIN" и "MAX" примерно
соответствует одному литру моторного масла.
Долив моторного масла
Если уровень масло в системе смазки
двигателя располагается около или ниже
метки "MIN", долейте моторное масло до
метки "MAX" через маслоналивную гор-
ловину B.
Уровень масла никогда не должен пре-
вышать метку "MAX".
ВАЖНО: Если в ходе проверки было ус-
тановлено, что уровень моторного масла
выше метки "MAX", обратитесь на стан-
цию технического обслуживания Fiat для
восстановления нормального уровня
масла.
ВАЖНО: После пополнения уровня или
замены моторного масла дайте двигате-
лю проработать несколько секунд, заглу-
шите его и через некоторое время вновь
проверьте уровень моторного масла.
РАСХОД МОТОРНОГО МАСЛА
Максимальный уровень расхода мотор-
ного масла составляет приблизительно
400 г на каждую 1 000 км пробега.
Если автомобиль новый, то на приработ-
ку деталей двигателя требуется некото-
рое время. Поэтому расход моторного
масла стабилизируется только после пер-
вых 5 000 - 6 000 км пробега.
ВАЖНО: Потребление масла во многом
определяется условиями эксплуатации и
стилем вождения.
ВАЖНО: При доливке не допускайте сме-
шивания разных сортов или марок мо-
торного масла.
198
SAFETY DEVICES
CORRECT USE OF THE CAR
W
ARNING
LIGHTS AND MESSAGES
IN AN
EMERGENCY
TE
CH
NI
CA
L
SP
EC
IFI
CA
TIO
NS
INDEX
DA
SH
BO
AR
D
AN
D
CO
NT
RO
LS
CA
R
MA
IN
TE
NA
NC
E
ENGINE OIL fig. 5-6-7-8
Checking engine oil
Check the oil level a few minutes (about
5) after the engine has stopped, with the
car parked on level ground.
Remove the dipstick A and clean it, put
it back in completely, remove it and check
that the level is within the MIN and MAX
marks on the dipstick. The interval be-
tween the MIN and MAX marks corre-
sponds to about one litre of oil.
fig. 5 - 1.4
16V
version
F0Q0665m
Topping up engine oil
If the oil level is near or even below the
MIN mark, add oil through the filler neck
B, until reaching the MAX mark.
Oil level shall never exceed the MAX
mark.
IMPORTANT If a routine check reveals
that the oil level is above the MAX mark,
contact Fiat Dealership to have the cor-
rect level restored.
IMPORTANT After adding or changing
the oil, let the engine turn over for a few
seconds and wait a few minutes after turn-
ing it off before you check the level.
fig. 7 - 1.9 Multijet
8V
version
F0Q0620m
fig. 8 - 1.9 Multijet
16V
version
A
B
F0Q0621m
Engine oil consumption
Max engine oil consumption is usually 400
grams every 1000 km.
When the car is new, the engine needs
to run in, therefore the engine oil con-
sumption can only be considered stabilised
after the first 5000 - 6000 km.
IMPORTANT The oil consumption de-
pends on driving style and the conditions
under which the car is used.
IMPORTANT Do not add oil with speci-
fications other than that already in the en-
gine.
F0Q0025m
fig. 6 - 1.4 T-JET version
191-212 BRAVO GB 10-05-2007 9:21 Pagina 198
Рис. 5 - Модели с двигателем
1,4 16V
198
SAFETY DEVICES
CORRECT USE OF THE CAR
W
ARNING
LIGHTS AND MESSAGES
IN AN
EMERGENCY
TE
CH
NI
CA
L
SP
EC
IFI
CA
TIO
NS
INDEX
DA
SH
BO
AR
D
AN
D
CO
NT
RO
LS
CA
R
MA
IN
TE
NA
NC
E
ENGINE OIL fig. 5-6-7-8
Checking engine oil
Check the oil level a few minutes (about
5) after the engine has stopped, with the
car parked on level ground.
Remove the dipstick A and clean it, put
it back in completely, remove it and check
that the level is within the MIN and MAX
marks on the dipstick. The interval be-
tween the MIN and MAX marks corre-
sponds to about one litre of oil.
fig. 5 - 1.4
16V
version
F0Q0665m
Topping up engine oil
If the oil level is near or even below the
MIN mark, add oil through the filler neck
B, until reaching the MAX mark.
Oil level shall never exceed the MAX
mark.
IMPORTANT If a routine check reveals
that the oil level is above the MAX mark,
contact Fiat Dealership to have the cor-
rect level restored.
IMPORTANT After adding or changing
the oil, let the engine turn over for a few
seconds and wait a few minutes after turn-
ing it off before you check the level.
fig. 7 - 1.9 Multijet
8V
version
F0Q0620m
fig. 8 - 1.9 Multijet
16V
version
A
B
F0Q0621m
Engine oil consumption
Max engine oil consumption is usually 400
grams every 1000 km.
When the car is new, the engine needs
to run in, therefore the engine oil con-
sumption can only be considered stabilised
after the first 5000 - 6000 km.
IMPORTANT The oil consumption de-
pends on driving style and the conditions
under which the car is used.
IMPORTANT Do not add oil with speci-
fications other than that already in the en-
gine.
F0Q0025m
fig. 6 - 1.4 T-JET version
191-212 BRAVO GB 10-05-2007 9:21 Pagina 198
Рис. 6 - Модели с двиг. 1,4 T-JET
198
SAFETY DEVICES
CORRECT USE OF THE CAR
W
ARNING
LIGHTS AND MESSAGES
IN AN
EMERGENCY
TE
CH
NI
CA
L
SP
EC
IFI
CA
TIO
NS
INDEX
DA
SH
BO
AR
D
AN
D
CO
NT
RO
LS
CA
R
MA
IN
TE
NA
NC
E
ENGINE OIL fig. 5-6-7-8
Checking engine oil
Check the oil level a few minutes (about
5) after the engine has stopped, with the
car parked on level ground.
Remove the dipstick A and clean it, put
it back in completely, remove it and check
that the level is within the MIN and MAX
marks on the dipstick. The interval be-
tween the MIN and MAX marks corre-
sponds to about one litre of oil.
fig. 5 - 1.4
16V
version
F0Q0665m
Topping up engine oil
If the oil level is near or even below the
MIN mark, add oil through the filler neck
B, until reaching the MAX mark.
Oil level shall never exceed the MAX
mark.
IMPORTANT If a routine check reveals
that the oil level is above the MAX mark,
contact Fiat Dealership to have the cor-
rect level restored.
IMPORTANT After adding or changing
the oil, let the engine turn over for a few
seconds and wait a few minutes after turn-
ing it off before you check the level.
fig. 7 - 1.9 Multijet
8V
version
F0Q0620m
fig. 8 - 1.9 Multijet
16V
version
A
B
F0Q0621m
Engine oil consumption
Max engine oil consumption is usually 400
grams every 1000 km.
When the car is new, the engine needs
to run in, therefore the engine oil con-
sumption can only be considered stabilised
after the first 5000 - 6000 km.
IMPORTANT The oil consumption de-
pends on driving style and the conditions
under which the car is used.
IMPORTANT Do not add oil with speci-
fications other than that already in the en-
gine.
F0Q0025m
fig. 6 - 1.4 T-JET version
191-212 BRAVO GB 10-05-2007 9:21 Pagina 198
Рис. 7 - Модели с двигателем 1,9
Multijet 8V
198
SAFETY DEVICES
CORRECT USE OF THE CAR
W
ARNING
LIGHTS AND MESSAGES
IN AN
EMERGENCY
TE
CH
NI
CA
L
SP
EC
IFI
CA
TIO
NS
INDEX
DA
SH
BO
AR
D
AN
D
CO
NT
RO
LS
CA
R
MA
IN
TE
NA
NC
E
ENGINE OIL fig. 5-6-7-8
Checking engine oil
Check the oil level a few minutes (about
5) after the engine has stopped, with the
car parked on level ground.
Remove the dipstick A and clean it, put
it back in completely, remove it and check
that the level is within the MIN and MAX
marks on the dipstick. The interval be-
tween the MIN and MAX marks corre-
sponds to about one litre of oil.
fig. 5 - 1.4
16V
version
F0Q0665m
Topping up engine oil
If the oil level is near or even below the
MIN mark, add oil through the filler neck
B, until reaching the MAX mark.
Oil level shall never exceed the MAX
mark.
IMPORTANT If a routine check reveals
that the oil level is above the MAX mark,
contact Fiat Dealership to have the cor-
rect level restored.
IMPORTANT After adding or changing
the oil, let the engine turn over for a few
seconds and wait a few minutes after turn-
ing it off before you check the level.
fig. 7 - 1.9 Multijet
8V
version
F0Q0620m
fig. 8 - 1.9 Multijet
16V
version
A
B
F0Q0621m
Engine oil consumption
Max engine oil consumption is usually 400
grams every 1000 km.
When the car is new, the engine needs
to run in, therefore the engine oil con-
sumption can only be considered stabilised
after the first 5000 - 6000 km.
IMPORTANT The oil consumption de-
pends on driving style and the conditions
under which the car is used.
IMPORTANT Do not add oil with speci-
fications other than that already in the en-
gine.
F0Q0025m
fig. 6 - 1.4 T-JET version
191-212 BRAVO GB 10-05-2007 9:21 Pagina 198
Рис. 8 - Модели с двигателем 1,9
Multijet 16V
