Для замены лампы действуйте следую-
щим образом:
откройте дверь багажного отсека и от-
верните два винта A, рис. 27;
снимите комбинированный фонарь,
сдвигая ее обеими руками в направле-
нии стрелок, как показано на рис. 28;
отсоедините электрический разъем и
снимите защитную крышку A, рис. 29,
нажав на три фиксатора защелки, после
чего замените перегоревшую лампу.
ФОНАРЬ ЗАДНЕГО ХОДА, рис. 30
Для замены лампы фонаря заднего хода
обращайтесь на станцию технического
обслуживания Fiat.
ЗАДНЯЯ ПРОТИВОТУМАННАЯ
ФАРА, рис. 31
Обратитесь на станцию технического
обслуживания Fiat для правильной за-
мены лампы заднего противотуманного
фонаря.
