НЕИСПРАВНОСТЬ
ВНЕШНИХ ОСВЕТИ-
ТЕЛЬНЫХ ПРИБОРОВ
(желтая)
Контрольная лампа (или символ на дис-
плее) загорается в случае, когда не горят
следующие фонари:
габаритные огни
стоп-сигналы ((или соответствующий
предохранитель), см. символ
BRAKE LIGHTS
FAILURE (amber)
The symbol on the display
turns on when a failure at brake
lights (stop) is detected.
The failure could be due to: blown bulb,
blown protection fuse or electric con-
nection cut-off.
On certain versions warning light W turns
on as an alternative.
