7-23

120

RX

Termination

Termination

120

TX

4

3

2

1

1

A

4

3

2

A

B

C

D

B

C

D

Unit 1

Interface

CNC

(Customer Supplied)

041993

CONTROL BOARD

1 2 3 4

S100

4

3

J303

2

1

2 3 4

1

J300A

J300B

CNC Interface Cable

J300A

S100

J300B

J303

CONTROL BOARD

Unit 2

J300A

S100

J300B

J303

CONTROL BOARD

Unit 3

J300A

J300B

S100

J303

CONTROL BOARD

Unit 4

CNC Interface Cable

CNC Interface Cable

CNC Interface Cable

Serial ID

Dipswitch

Machine Motion

Jumper Block

Jumper Block

Machine Motion

Dipswitch

Serial ID

Jumper Block

Machine Motion

Dipswitch

Serial ID

Jumper Block

Machine Motion

Dipswitch

Serial ID

J106

2

1

J107

1 2

J106

1 2

1 2

J107

J106

1 2

1 2

J107

J106

1 2

1 2

J107

Optional Multi-System Interface

5 6 7 8

Switch 1 is in the On position

Switches 2-8 are in the Off position

ON

1 2 3 4 5 6 7 8

ON

1 2 3 4 5 6 7 8

ON

1 2 3 4 5 6 7 8

ON

1 2 3 4

S101

ON

041993

1 2 3 4

S101

ON

041993

1 2 3 4

S101

ON

041993

1 2 3 4

S101

ON

4

3

2

1

2 3 4

1

4

3

2

1

2 3 4

1

4

3

2

1

2 3 4

1

Notes:
1) For single system installations set Serial ID (S100), and Machine Motion (J303) as shown in Unit 1,

jumpers J106 and J107 must be closed.

2) On multi-system installations refer to the illustration.

Jumpers J106 and J107 are left open on all systems except for the very last system where

they are in the closed position.

Termination resistors (120-ohm) or termination jumpers must be installed/set at the CNC for

each of the RS-422 RX and TX signal pairs.

3) If a Hypertherm Automation Controller is being used, and there are intermittent communication

failures (PS Link Failure), try removing the jumpers on J106 and J107 on the control board, and the

termination jumper (J6 or J8) on the serial isolation board in the controler. Only remove

the termination jumper on the serial isolation board that is connected to the HPR

power supply. See sheet 17 for more details.

HPR PAC

Dry Cutting System

HPR PAC

Dry Cutting System

HPR PAC

Dry Cutting System

HPR PAC

Dry Cutting System

S100

1 2 3 4 5 6 7 8

Dipswitch setting example:

2

1

3 4

5 6

7 8

ON

ELEC SCH:HPR260XD PWR SPLY W/AUTO

B

013378

SHEET 19 OF 22
