84
CLP-295GP Руководство пользователя
настройка глубины эффекта
Spatial [SpatialFX Depth]
Эффект Spatial является одним из разновид-
ностей iAFC эффекта. Spatial Effect создает
ощущение реверберации и пространственности
путем считывания звукового выхода при помощи
внутренних и воспроизводить звук через дина-
мик, находящийся на задней панели инструмен-
та. Эффект пространственности звука отличен
в зависимости от его глубины. При настройке
более низкой глубины эффекта, создается резо-
нанс и усиливается акустический реализм звука,
как при игре на акустических инструментах. Для
настойки большей глубины эффекта, звук ин-
струмента воспроизводится через внутренние
микрофоны, и обрабатывается с целью имитации
трехмерного звучания.
Действия см. на стр 71.
84
CLP-295GP Owner’s Manual
Detailed Settings
Detailed settings for iAFC [iAFC SETTING]
Spatial Effect is one type of the iAFC effect. Spatial
Effect creates a sense of reverberation and spa-
ciousness by picking up the output sound using
internal microphones and output the sound from
the speaker on the rear of the instrument. The
spread and spaciousness of the sound is different
depending on the depth. For lower depth settings,
this creates the resonance and enhances the acous-
tic realism of the sound that is characteristic of
acoustic instruments by creating a virtual sound-
board. For deeper depth settings, the sound of the
instrument itself and the sound of singing and
other instruments played nearby is picked up by
internal microphones, and processed to simulate
the spatial characteristics of performing together
on stage.
See the procedure on page 71.
Setting range:
0 - 127
This automatically adjusts the sensitivity and
response of iAFC so that the optimal iAFC effect
will be obtained.
When automatic adjust begins, a test sound (noise)
will sound for about five seconds.
While automatic adjustment is being performed,
do not make audible noises in the vicinity of the
Clavinova.
See the procedure on page 71.
The keyboard will not produce sound while automatic adjust-
ment is being performed. Nor is it possible to adjust the vol-
ume of the Clavinova.
This sets the calibration function to the default set-
ting.
See the procedure on page 71.
Adjusting the Spatial Effect depth
[SpatialFX Depth]
Calibration (automatic adjustment)
[Calibration]
B
D
NO YES
A
C
SpatialFX Depth
10
B
D
NO YES
A
C
Calibration Sure?-->
Test sound is output.
TIP
Restoring the default calibration set-
ting [iAFC Default]
B
D
NO YES
A
C
iAFC Default Set?-->
диапазон установок:
0-127
калибровка (автоматическая настройка)
[Calibration]
Данная функция автоматически настраивает
чувствительность iAFC, и таким образом, можно
добиться наиболее оптимального звучания iAFC
эффекта.
Когда начинается автоматическая настройка, в
течение 5 секунд слышится тестовый звук.
По окончании автоматической настройки, не
воспроизводите акустический (низкочастотный)
шум рядом с цифровым пианино Clavinova.
Действия см. на стр 71.
84
CLP-295GP Owner’s Manual
Detailed Settings
Detailed settings for iAFC [iAFC SETTING]
Spatial Effect is one type of the iAFC effect. Spatial
Effect creates a sense of reverberation and spa-
ciousness by picking up the output sound using
internal microphones and output the sound from
the speaker on the rear of the instrument. The
spread and spaciousness of the sound is different
depending on the depth. For lower depth settings,
this creates the resonance and enhances the acous-
tic realism of the sound that is characteristic of
acoustic instruments by creating a virtual sound-
board. For deeper depth settings, the sound of the
instrument itself and the sound of singing and
other instruments played nearby is picked up by
internal microphones, and processed to simulate
the spatial characteristics of performing together
on stage.
See the procedure on page 71.
Setting range:
0 - 127
This automatically adjusts the sensitivity and
response of iAFC so that the optimal iAFC effect
will be obtained.
When automatic adjust begins, a test sound (noise)
will sound for about five seconds.
While automatic adjustment is being performed,
do not make audible noises in the vicinity of the
Clavinova.
See the procedure on page 71.
The keyboard will not produce sound while automatic adjust-
ment is being performed. Nor is it possible to adjust the vol-
ume of the Clavinova.
This sets the calibration function to the default set-
ting.
See the procedure on page 71.
Adjusting the Spatial Effect depth
[SpatialFX Depth]
Calibration (automatic adjustment)
[Calibration]
B
D
NO YES
A
C
SpatialFX Depth
10
B
D
NO YES
A
C
Calibration Sure?-->
Test sound is output.
TIP
Restoring the default calibration set-
ting [iAFC Default]
B
D
NO YES
A
C
iAFC Default Set?-->
ПрИмечаНИе:
клавиатура не будет воспроизводить звук до тех пор,
пока не будет произведена автоматическая настройка
и регулировка громкости.
восстановление настройки стандартной
калибровки [iAFC Default]
Данная функция позволяет восстановить на-
стройки стандартной калибровки.
Действия см. на стр 71.
84
CLP-295GP Owner’s Manual
Detailed Settings
Detailed settings for iAFC [iAFC SETTING]
Spatial Effect is one type of the iAFC effect. Spatial
Effect creates a sense of reverberation and spa-
ciousness by picking up the output sound using
internal microphones and output the sound from
the speaker on the rear of the instrument. The
spread and spaciousness of the sound is different
depending on the depth. For lower depth settings,
this creates the resonance and enhances the acous-
tic realism of the sound that is characteristic of
acoustic instruments by creating a virtual sound-
board. For deeper depth settings, the sound of the
instrument itself and the sound of singing and
other instruments played nearby is picked up by
internal microphones, and processed to simulate
the spatial characteristics of performing together
on stage.
See the procedure on page 71.
Setting range:
0 - 127
This automatically adjusts the sensitivity and
response of iAFC so that the optimal iAFC effect
will be obtained.
When automatic adjust begins, a test sound (noise)
will sound for about five seconds.
While automatic adjustment is being performed,
do not make audible noises in the vicinity of the
Clavinova.
See the procedure on page 71.
The keyboard will not produce sound while automatic adjust-
ment is being performed. Nor is it possible to adjust the vol-
ume of the Clavinova.
This sets the calibration function to the default set-
ting.
See the procedure on page 71.
Adjusting the Spatial Effect depth
[SpatialFX Depth]
Calibration (automatic adjustment)
[Calibration]
B
D
NO YES
A
C
SpatialFX Depth
10
B
D
NO YES
A
C
Calibration Sure?-->
Test sound is output.
TIP
Restoring the default calibration set-
ting [iAFC Default]
B
D
NO YES
A
C
iAFC Default Set?-->
Детальные настройки для iAFC [iAFC SETTING]
