48
En
Operating various settings for this unit (Setup menu)
The Setup menu screen appears on both the GUI screen
and front panel display.
GUI screen
Front panel display
In this section, procedures of setting menus using the
video monitor are described.
1
Press iON SCREEN on the remote control.
The GUI screen appears on the video monitor.
2
Press jCursor n to select “Setup” and then
press jENTER.
The Setup menu appears on the video monitor.
3
Press jCursor k / n to select the desired
menu then press jENTER.
Items of the selected menu are displayed.
Example (Function Setup)
y
• To return to the previous menu, press jRETURN.
4
If necessary, press jCursor k / n to select
the desired submenu then press jENTER.
Example (Volume)
5
Press jCursor k / n to select an item to edit
and then press jCursor l / h to change
the setting.
Some items in “Manual Setup” of “Speaker Setup”
take up a full screen. To display other items in
“Manual Setup”, press jCursor k / n.
Example (Speaker Configuration)
y
• To configure other items, repeat step 5.
6
To turn off the GUI screen, press iON
SCREEN.
Note
• In case jCursor k / n / l / h or other keys do not work after
closing the Setup menu, press dInput selection key to
select the current input source again.
You can set various items for speakers. Two kinds of
adjustments are available. One is “Auto Setup” (YPAO)
for automatic adjustment and another is “Manual Setup”
for manual adjustment.
y
• The default settings are marked with “*”.
Automatically adjusts output characteristics of speakers to
obtain optimum balance for the output sound based on
positions and performances of the speakers and acoustic
characteristics or the room, which are automatically
measured. For details on operations, see page 21.
Adjusts output characteristics of speakers based on
manually set parameters.
After “Auto Setup” (YPAO) is performed, you can check
automatically adjusted parameters in the “Manual Setup”
menu. Fine adjust the parameters for your preference if
necessary.
■ Speaker Configuration
Sets speaker configurations, such as connection status of
speaker and a size of the connected speaker (sound
reproduction capacity), suitable for the listening
environment.
y
• The speaker configuration includes items for defining a speaker size:
“Large” or “Small”. “Large” and “Small” refer to speakers with woofer
diameters 16 cm or larger and smaller than 16 cm, respectively.
Basic operation of the Setup menu
Speaker Setup
Sound Setup
Function Setup
DSP Parameter
Memory Guard
Setup Menu
;Speaker Setup
HDMI
Display
Volume
Input Rename
Zone
Network
Function Setup
Off
+16.5dB
Off
Volume
Adaptive DRC
Max Volume
Initial Volume
Speaker Setup
Auto Setup
Manual Setup
Speaker Configuration
Front Speaker
Large Small
