Sulky Seed Master - Инструкция (Страница 81)

79
GB
Troubleshooting
1
6
N OT ABLE TO ADJUST OPENER
PRESSURE .
N OT ABLE TO LOWER METER
WHEEL .
N OT ABLE TO LOWER WINGS .
Opener cylinder seal is leaking.
Faulty opener pressure gauge.
The opener orifice may be
plugged.
Wiring up to meter wheel
solenoid valve is faulty.
Meter wheel solenoid valve is
not moving due to a faulty
electric coil.
Meter wheel solenoid valve
cartridge is contaminated.
The machine is not on level
ground.
The in pressure gauge reads less
than 1500 psi.
The wing up pressure gauge
reads more than 100 psi.
No 12 V power coming to fast
wing valve.
Fast wing valve is contaminated.
Wing valve cartridge is
contaminated.
Wing relief valve is set too low.
Contact your dealer before doing
anything: Sulky cannot be held
responsible if this operation has
not been done correctly.
Replace gauge. Ensure the new
gauge has a range of 0 to1500
psi.
Contact your dealer before doing
anything: Sulky cannot be held
responsible if this operation has
not been done correctly.
Using a test light, check that
there is power at the meter
wheel solenoid valve when the
meter wheel switch is on.
Contact your dealer before doing
anything: Sulky cannot be held
responsible if this operation has
not been done correctly.
Contact your dealer before doing
anything: Sulky cannot be held
responsible if this operation has
not been done correctly.
Ensure that the implement is
parked on level ground, and the
area is clear of overhead power
lines.
Check the quick couplers for
red-green circuit; they may be
uncoupled or poorly mated.
Check the quick couplers for the
manifold out line (1/2" line
marked with a red sleeve) for
red-green circuit; they may be
uncoupled or poorly mated.
Use test light to check for
power.
Contact your dealer before doing
anything: Sulky cannot be held
responsible if this operation has
not been done correctly.
Contact your dealer before doing
anything: Sulky cannot be held
responsible if this operation has
not been done correctly.
Contact your dealer before doing
anything: Sulky cannot be held
responsible if this operation has
not been done correctly.
S YMPTOM P OSSIBLE C AUSE S OLUTION
