Hypertherm MAX200 Hand Torch Plasma Arc Cutting System - Инструкция (Страница 165)

PLASMA
GAS
SHIELD
GAS
GAS
PLASMA
TORCH
CAP
NOZZLE
CAP
GAS
SHIELD
V1
V3 V5
V9
PS1
60psi
V5 V2
PS3
4psi
PS4
26psi
PG1
V4
PG2
CO1
CO3
CO2
PS2
70psi
GAS FLOW DIAGRAM
PLASMA STEP GAS SOLENOID VALVE
SHIELD GAS SOLENOID
PLASMA PRE/POST FLOW SOLENOID VALVE
MAIN CONTACTOR
V1
V3
V2
CON1
MAX200 TIMING CHART
CAP-ON-SENSE SOLENOID VALVE V4
PLASMA CHARGING VALVE V9
POWER ON SWITCH PB1
POWER OFF SWITCH PB2
PLASMA GAS OUTLET PRESSURE SWITCH. N.O. SWITCH PS3
QUICK CHARGE PRESSURE SWITCH. N.C. SWITCH PS4
PLASMA START SIGNAL FROM CNC START
PLASMA STOP SIGNAL FROM CNC STOP
ARC TRANSFER XFER
1 SECOND GAS FLOW AT END OF CYCLE POST-FLOW
GAS SYSTEM DESIGNATOR
TIMING CHART MAX200
PB1 START PS3 XFER PS4 STOP POST PB2
FLOW
V9
V4
V3
V2
V1
CON1
THAT CLOSES WHEN THE PLASMA GAS PRESSURE
EXCEEDS 3 psi
THAT OPENS WHEN PLASMA GAS REACHES 26 psi
NOTES:
1. IN TEST MODE, V1, V2, AND V3 ARE THE ONLY VALVES THAT ARE
ACTIVE.
2. WHEN V1 BECOMES ACTIVE AFTER START, 10 TO 15 psi WILL BE
REGISTERED AT PG1.
3. THE HV TRANSFORMER IS ACTIVATED 2 SECONDS AFTER THE PLASMA
START SIGNAL. IT WILL STAY ACTIVE FOR 5 SECONDS OR UNTIL THE
ARC TRANSFERS TO THE WORK PIECE, WHICH EVER HAPPENS FIRST.
013179 013-2-179 013179B9
ELEC/GAS SCHEM: MAX200
N/A MAX200 9 OF 9
BC 5-9-96
