16
Troubleshooting
If a problem still remains after applying the suggested remedies, contact your local EIZO representative.
●
No picture
Problem Possible cause and remedy
1. No picture
• None of the operation buttons ( / / )
light up.
• Check whether the power cord is connected properly.
• Turn the main power switch on.
• Turn off the main power, and then turn it on again a
few minutes later.
• Only the button lights up orange. • Press .
• All of the operation buttons ( / / ) light
up orange.
• Adjust the brightness (brilliance) of the screen.
• Operate the mouse or keyboard.
• Check whether the PC is turned on.
2. The message below appears. This message appears when the signal is not input
correctly even when the monitor functions properly.
• This message appears when no signal is
input.
Example:
• The message shown left may appear, because some
PCs do not output the signal soon after power-on.
• Check whether the PC is turned on.
• Check whether the signal cable is connected properly.
• The message shows that the input signal is out
of the specified frequency range. (Such signal
frequency is displayed in magenta.)
Example:
fD: Dot clock
(Displayed only during digital signal input)
fH: Horizontal scan frequency
fV: Vertical scan frequency
• Check whether the PC is configured to meet the
resolution and vertical scan frequency requirements
of the monitor. (“Compatible Resolutions” in the Setup
Manual.)
• Reboot the PC.
• Select an appropriate display mode using the
graphics board’s utility. Refer to the manual of the
graphics board for details.
