56
En
Controlling other components with the remote control
The remote control of this unit can receive remote control signals from other remote controls and learn the remote control
operation. If a key on the remote control does not work after being assigned with an external component’s function or if
the remote control code for that function is not provided, use this learning feature to make the function operable with the
remote control.
y
• Each of the steps described in this section should be performed within one minute. Setting operation is automatically canceled when one minute has
passed since the last step. If the operation is cancelled, start again from the beginning.
You can program the remote control to make functions of
an external component operable with the following keys.
You can assign functions to these keys for each input
source as with remote control codes.
dSOURCE POWER
lExternal component operation keys
mNumeric keys
y
• The remote control transmits infrared rays. If the remote control of the
external component also uses infrared rays, this remote control can learn
most of its functions. The remote control may not recognize special or
consecutive signals.
• The keys may not operate the assigned functions depending on operating
conditions of this unit.
1
Press oCODE SET on the remote control
using a pointed object such as the tip of a
ballpoint pen.
cTRANSMIT on the remote control blinks twice.
2
Press eInput selection keys to select the
input source whose function you want to
assign to the remote control.
3
Enter “9990” using mNumeric keys.
4
Press a key to which you want to assign the
function.
cTRANSMIT lights up and this unit enters a wait
state to receive remote control signals. Do steps 5 and
6 within 10 seconds.
Note
• If 10 seconds pass after this unit enters the wait state, a timeout
error occurs and cTRANSMIT turns off. If this occurs, repeat
from step 4.
5
Place the remote control about 5 to 10 cm
apart from the remote control of the external
component on a flat surface so that their
infrared transmitters are aimed at each other.
Note
• If 10 seconds pass after step 4 is performed, an error occurs and
this unit cannot receive remote control signals. If cTRANSMIT
turns off before you do step 6, repeat from step 4.
6
Press the key on the remote control of the
external component.
The function assigned to the selected key is also
assigned to the key that you have selected in step 4.
When the function is assigned to the key successfully,
cTRANSMIT on the remote control blinks twice.
If it fails, cTRANSMIT blinks six times. Repeat
from step 4.
y
• To continue assigning other functions, repeat steps 4 through 6.
7
To end programming, press oCODE SET on
the remote control using a pointed object
such as the tip of a ballpoint pen.
cTRANSMIT on the remote control blinks once.
Programming from other remote controls
Programming the remote control of this
unit
MAIN PO
WER 12
3
4
12
56 12
3
4
PO
WER
SOURCE V- A U X
PHONO
[ A
]
DOCK MUL
TI
TUNER FM MO
VIE BD DV
D
MUSIC
SCENE TV
CD OPTION
SETUP
RADIO
STEREO ENHANCER
SUR.
DECODE
PURE DIRECT
STRAIGHT
INFO
MEMOR
Y
AM
PRESET
SLEEP HDMI
AV
AU
D
IO
ZONE2
TRANSMIT
CODE SET TUNING
Remote control of external
component
5 to 10 cm
