MAIN MENU
PROCESS VARS
DISPLAY STATUS
DEVICE STATUS
DISPLAY SETUP
DEVICE SETUP
DEVICE CAL
DISPLAY TEST
DEVICE TEST
PROCESS VARS
GAS NAME XXXXX
GAS VALUE X.XX
HIGH ALARM Y/N
LOW ALARM Y/N
ANALOG INPUT X.XX MA
URV X.XX
LRV X.XX
FAULT Y/N
HISTORY
DISPLAY HISTORY
EVENT LOG
DISPLAY INFO
RTC
SERIAL NUMBER
XXXXX
I/O BOARD ID XXX
MFG DATE DD/MM/YYYY
F/W REV XXXXX
UNIVERSAL REV XXXXX
FIELD DEV REV XXXXX
RUNNING HOURS XXXXX
TEMPERATURE XX.XX C
HEATER CTRL AUTO/ON/OFF
BACKLIGHT CTRL AUTO/ON/OFF
INPUT VOLTAGE XX.XX
EVENT LOG
EVENT XXXXX
DATE DD/MMM/YYYY
TIME HH:MM:SS
RTC
DISPLAYED Y/N
SECONDS XX
MINUTES XX
HOURS XX
DAY XX
MONTH XX
YEAR XX
GENERAL OPTIONS
TAG XXXXX
DESCRIPTOR XXXXX
MESSAGE XXXX
FINAL ASSY NUM XXXX
RTC
SECONDS XX
MINUTES XX
HOURS XX
DAY XX
MONTH XX
YEAR XX
HISTORY
DEVICE HISTORY
CALIBRATION LOG
EVENT LOG
DEVICE HISTORY
RUNNING HOURS XXXX
MAX TEMP XX.XX C
MAX TEMP TIME X:XX:XX
MIN TEMP XX.XX C
MIN TEMP TIME X:XX:XX
RESET MAX MIN
MAX RESET TEMP
XX.XX C
MAX RESET TIME X:XX:XX
MIN RESET TEMP XX.XX C
MIN RESET TIME X:XX:XX
GENERAL INFO
MANUFACTURER
MODEL
OPECL_RX
TAG XXXXX
DESCRIPTOR XXXXX
MESSAGE XXXXX
FINAL ASSY NUM XXXX
DEVICE ID XXXXX
FAULT/STATUS
OP MODE XXXXX
CAL STATE XXXXX
FAULT Y/N
STATUS Y/N
DEVICE INFO
RTC
SERIAL NUMBER
XXXXX
UNIVERSAL REV XXXXX
FIELD DEV REV XXXXX
S/W REV XXXXX
SENSOR INFO
ACTIVE XX.XX
REFERENCE XX.XX
RATIO XX.XX
GAS GAIN XX.XX
TEMPERATURE XX.XX C
ABSORPTION XX.XX
COEFFICIENT
COEFFICIENT
COEFF A X.XXXXX
COEFF B X.XXXXX
COEFF C X.XXXXX
COEFF D X.XXXXX
COEFF E X.XXXXX
DEVICE STATUS
GENERAL INFO
FAULT/STATUS
DEVICE INFO
SENSOR INFO
HISTORY
EVENT LOG
EVENT XXXXX
DTIME MM/DD - HH:MM
CALIBRATION LOG
CAL ID XXXXX
DTIME MM/DD - HH:MM
STATUS
CAL ACTIVE ON/OFF
WARM UP ON/OFF
LOW ALARM ON/OFF
HIGH ALARM ON/OFF
HART SELF TEST ON/OFF
ALIGN MODE ON/OFF
CHANGE CONFIG ON/OFF
FAULT
CAL FAULT ON/OFF
DIRTY OPTICS ON/OFF
LAMP FAULT ON/OFF
START CAL FAULT ON/OFF
EE FAULT ON/OFF
NOISE FAULT ON/OFF
REF ADC SAT ON/OFF
ACTIVE ADC SAT ON/OFF
24V FAULT ON/OFF
ALIGN ADC SAT ON/OFF
ALIGN FAULT ON/OFF
ZERO DRIFT FAULT ON/OFF
FLASH CRC FAULT ON/OFF
RAM FAULT ON/OFF
ALIGN WARNING ON/OFF
BLOCKED OPTICS ON/OFF
DEVICE SETUP
DEVICE OPTION
ALARM SETTING
HART OPTION
RS485
RTC
HART OPTION
TAG XXXXX
DESCRIPTOR XXXXX
MESSAGE XXXXX
FINAL ASSY NUM XXXXX
DEVICE OPTION
GAS NAME
UNIT OF MEASURE
URV
XXXXX
LRV XXXXX
USL XXXXX
LSL XXXXX
ANALOG CODE VAL
ANALOG FLT CODE
BLOCK OPTIC TIME
XXXXX
HEATER CONTROL X
RS485
BAUD RATE
PARITY
POLL ADDRESS
XXX
BAUD RATE
1200
2400
4800
9600
19.2K
PARITY
NONE
EVEN
ODD
ALARM SETTING
RST LATCH ALARMS
HGH ALARM LEVEL
XXXXX
HGH ALARM LATCH Y/N
LOW ALARM LEVEL XXXXX
LOW ALARM LATCH Y/N
ANALOG CODE VAL
WARM UP XXXXXX
BLOCKED OPTIC XXXXXX
CALIBRATION XXXXXX
FAULT XXXXXX
GAS NAME
METHANE
ETHANE
PROPANE
PROPYLENE
BUTANE
SPECIAL
ANALOG FAULT CODE
OPECL
PIR9400
USER DEFINED
RTC
SYNC W/DISP
SECONDS
XXXX
MINUTES XXXX
HOURS XXXX
DAY XXXX
MONTH XXXX
YEAR XXXX
D/A TRIM
ZERO TRIM
GAIN TRIM
DEVICE TEST
SELF TEST
RESPONSE TEST
LOOP TEST
D/A TRIM
SET 4-20 MA
3.5 MA
4 MA
6 MA
8 MA
10 MA
12 MA
14 MA
16 MA
18 MA
20 MA
LOOP TEST
SET 4-20 MA
DEVICE CAL
CAL GAS CONC XX.XX
CAL GAS TYPE
ZERO CALIBRATION
SPAN CAL FACTOR
XXXXX
CAL DATE DD/MMM/YYYY
CALIBRATION
EXECUTE
ABORT
UNIT OF MEASURE
LFLM
VOLM
PPMM
DISPLAY TEST
SELF TEST
RESPONSE TEST
DISPLAY SETUP
MODE SELECT
GENERAL OPTIONS
INPUT LOOP CAL
CONTRAST CONTRL
BACKLIGHT CTRL
MODE SELECT
HART DEVICE
PIR9400
C706X
505
NTMOS
CGS
GENERIC DEVICE
DISPLAY STATUS
GENERAL INFO
FAULT/STATUS
LON CONFIG
HISTORY
DISPLAY INFO
DEBUG MENU
GENERAL INFO
MANUFACTURER
MODEL
UD-10
TAG XXXXX
DESCRIPTOR XXXXX
MESSAGE XXXXX
FINAL ASSY NUM XXXXX
DEVICE ID XXXXX
STATUS
ANY FAULT ON/OFF
CAL . ACTIVE ON/OFF
WARM UP ON/OFF
LOW ALARM ON/OFF
HIGH ALARM ON/OFF
LON ATTACHED ON/OFF
RESPONSE TEST ON/OFF
MANUAL SELF TEST ON/OFF
INPUT HART ON/OFF
FAULT/STATUS
OP MODE XXXXX
FAULT Y/N
STATUS Y/N
LON FAULT Y/N
6901 WEST 110TH STREET
MINNEAPOLIS, MN 55438
USA
6901 WEST 110TH STREET
MINNEAPOLIS, MN 55438
USA
CAL GAS TYPE
SAME AS MEASURE GAS
METHANE
PROPANE
DEBUG MENU
HART ERRORS XXXXX
ANALOG INPUT XX.XX MA
LON COMM ERRORS XXXX
FAULT
EE FAULT ON/OFF
ADC FAULT ON/OFF
24V FAULT ON/OFF
FLASH FAULT ON/OFF
RAM FAULT ON/OFF
WDT FAULT ON/OFF
12V FAULT ON/OFF
5V FAULT ON/OFF
3V FAULT ON/OFF
INPUT LOOP FAULT ON/OFF
LON CONFIG
HGH ALARM LEVEL XX.XX
LOW ALARM LEVEL XX.XX
CAL GAS CONC XX.XX
STATUS RATE XXXXXX
LON ADDRESS XXXXXX
LON FAULT
INVALID CONFIG ON/OFF
LON OFFLINE ON/OFF
TERM BD FAULT ON/OFF BACKLIGHT CTRL
OFF
ON
AUTOMATIC
DISPLAY HISTORY
RUNNING HOURS XXXX
MAX TEMP XX.XX C
MAX TEMP TIME XX:XX:XX
MIN TEMP XX.XX C
MIN TEMP TIME XX:XX:XX
RESET MAX MIN
MAX RESET TEMP
XX.XX C
MAX RESET TIME XX:XX:XX
MIN RESET TEMP XX.XX C
MIN RESET TIME XX:XX:XX
