MAIN MENU
PROCESS VARS
DISPLAY STATUS
DEVICE STATUS
DISPLAY SETUP
DEVICE SETUP
DEVICE CAL
DISPLAY TEST
DEVICE TEST
PROCESS VARS
GAS NAME
XXXXX
GAS VALUE
X.XX
HIGH ALARM
Y/N
LOW ALARM
Y/N
ANALOG INPUT
X.XX MA
URV
X.XX
LRV
X.XX
FAULT
Y/N
DISPLAY STATUS
GENERAL INFO
FAULT/STATUS
LON CONFIG
HISTORY
DISPLAY INFO
DEBUG MENU
DISPLAY SETUP
MODE SELECT
GENERAL OPTIONS
INPUT LOOP CAL
CONTRAST CONTRL
BACKLIGHT CTRL
DISPLAY TEST
SELF TEST
RESPONSE TEST
FAULT/STATUS
OP MODE
XXXXX
FAULT
Y/N
STATUS
Y/N
LON FAULT
Y/N
GENERAL INFO
MANUFACTURER
MODEL
UD-10
TAG
XXXXX
DESCRIPTOR
XXXXX
MESSAGE
XXXXX
FINAL ASSY NUM
XXXXX
DEVICE ID
XXXXX
HISTORY
DISPLAY HISTORY
EVENT LOG
DISPLAY INFO
RTC
SERIAL NUMBER
XXXXX
I/O BOARD ID
XXX
MFG DATE
DD/MM/YYYY
F/W REV
XXXXX
UNIVERSAL REV
XXXXX
FIELD DEV REV
XXXXX
RUNNING HOURS
XXXXX
TEMPERATURE
XX.XX C
HEATER CTRL
AUTO/ON/OFF
BACKLIGHT CTRL
AUTO/ON/OFF
INPUT VOLTAGE
XX.XX
STATUS
ANY FAULT
ON/OFF
CAL
.
ACTIVE
ON/OFF
WARM UP
ON/OFF
LOW ALARM
ON/OFF
HIGH ALARM
ON/OFF
LON ATTACHED
ON/OFF
RESPONSE TEST
ON/OFF
MANUAL SELF TEST
ON/OFF
INPUT HART
ON/OFF
EVENT LOG
EVENT
XXXXX
DATE
DD/MMM/YYYY
TIME
HH:MM:SS
RTC
DISPLAYED
Y/N
SECONDS
XX
MINUTES
XX
HOURS
XX
DAY
XX
MONTH
XX
YEAR
XX
MODE SELECT
HART DEVICE
PIR9400
C706X
505
NTMOS
CGS
GENERIC DEVICE
D/A TRIM
ZERO TRIM
GAIN TRIM
DEVICE TEST
SELF TEST
RESPONSE TEST
LOOP TEST
D/A TRIM
LOOP TEST
SET 4-20 MA
DEVICE CAL
CAL GAS CONC
XX.XX
CALIBRATION
CHANGE SNSR TYPE
CALIBRATION
EXECUTE
ABORT
DEVICE SETUP
DEVICE OPTION
HART OPTION
RTC
DEVICE STATUS
GENERAL INFO
FAULT/STATUS
TX INFO
SENSOR INFO
HISTORY
DEBUG MENU
HISTORY
TX HISTORY
SENSOR HISTORY
CALIBRATION LOG
EVENT LOG
GENERAL INFO
MANUFACTURER
MODEL
FGP_TX
TAG
XXXXX
DESCRIPTOR
XXXXX
MESSAGE
XXXX
FINAL ASSY NUM
XXXXX
DEVICE ID
XXXXX
FAULT/STATUS
OP MODE
XXXXX
CAL STATE
XXXXX
TX STATUS
Y/N
TX FAULT
Y/N
SENSOR STATUS
Y/N
SENSOR FAULT
Y/N
TX INFO
RTC
SERIAL NUMBER
XXXXX
H/W REV
XX.XX
F/W REV
XX.XX
UNIVERSAL REV
XXXXX
FIELD DEV REV
XXXXX
S/W REV
XX.XX
RUNNING HOURS
XXXXX
TEMPERATURE
XX.XXC
SENSOR INFO
SENSITIVITY
XXXXX
GAS TYPE
XXXXX
SERIAL NUMBER
XXXXX
H/W REV
XX.XX
F/W REV
XX.XX
REV
XXXXX
USL
XX.XX
LSL
XX.XX
RUNNING HOURS
XXXXX
CAL POINT ZERO
XX.XX
CAL POINT SPAN
XX.XX
PPM HOURS
XXXXX
TEMPERATURE
XX.XXC
EVENT LOG
EVENT
XXXXX
DATE
DD/MMM/YYYY
TIME
HH:MM:SS
CALIBRATION LOG
CAL ID
XXX
DATE
DD/MMM/YYYY
TIME
HH:MM:SS
ZERO
XX.XX
SPAN
XX.XX
RTC
SECONDS
XX
MINUTES
XX
HOURS
XX
DAY
XX
MONTH
XX
YEAR
XX
DEBUG MENU
HART ERRORS
XXXXX
ANALOG INPUT
XX.XX MA
LON COMM ERRORS
XXXX
SET 4-20 MA
3.5 MA
4 MA
6 MA
8 MA
10 MA
12 MA
14 MA
16 MA
18 MA
20 MA
6901 WEST 110TH STREET
MINNEAPOLIS, MN 55438
USA
TX HISTORY
RUNNING HOURS
XX:XX:XX
MAX TEMP
XX.XX C
MAX TEMP TIME
XX:XX:XX
MIN TEMP
XX.XX C
MIN TEMP TIME
XX:XX:XX
DISPLAY HISTORY
RUNNING HOURS
XXXX
MAX TEMP
XX.XX C
MAX TEMP TIME
XX:XX:XX
MIN TEMP
XX.XX C
MIN TEMP TIME
XX:XX:XX
RESET MAX MIN
MAX RESET TEMP
XX.XX C
MAX RESET TIME
XX:XX:XX
MIN RESET TEMP
XX.XX C
MIN RESET TIME
XX:XX:XX
TX STATUS
TX FAULT
ON/OFF
WARM UP
ON/OFF
CHANGE CONFIG
ON/OFF
MULTI DROP
ON/OFF
WRITE PROTECT
ON/OFF
SELF TEST
ON/OFF
RESPONSE TEST
ON/OFF
CURRENT FIXED
ON/OFF
LOOP TEST
ON/OFF
FACTORY MODE
ON/OFF
SNSR ASSY REMOVE
ON/OFF
TX FAULT
EE FAULT
ON/OFF
ADC FAULT
ON/OFF
DAC FAULT
ON/OFF
LOW VOLTAGE
ON/OFF
FLASH CRC FAULT
ON/OFF
RAM FAULT
ON/OFF
TEMP FAULT
ON/OFF
SOFTWARE FAULT
ON/OFF
EE SAFETY FAULT
ON/OFF
ZERO DRIFT FAULT
ON/OFF
SENSOR MISMATCH
ON/OFF
SENSOR FAULT
ON/OFF
SENSOR STATUS
SENSOR FAULT
ON/OFF
WARM UP
ON/OFF
CAL ACTIVE
ON/OFF
CAL SWITCH
ON/OFF
WRITE PROTECT
ON/OFF
EOL SENSOR
ON/OFF
CHANGE CONFIG
ON/OFF
GEN ACTIVE
ON/OFF
GEN INSTALLED
ON/OFF
SENSOR FAULT
CAL FAULT
ON/OFF
EE FAULT
ON/OFF
ADC FAULT
ON/OFF
ADC CNTR FAULT
ON/OFF
3V FAULT
ON/OFF
ZERO DRIFT FAULT
ON/OFF
FLASH CRC FAULT
ON/OFF
RAM FAULT
ON/OFF
TEMP FAULT
ON/OFF
COMM FAULT
ON/OFF
GEN FAULT
ON/OFF
DEBUG MENU
MODBUS ERRORS
XXXX
SENSOR HISTORY
RUNNING HOURS
XXXX
MAX TEMP
XX.XX C
MAX TEMP TIME
XX:XX:XX
MIN TEMP
XX.XX C
MIN TEMP TIME
XX:XX:XX
RESET MAX MIN
MAX RESET TEMP
XXXX C
MIN RESET TEMP
XXXX C
FAULT
EE FAULT
ON/OFF
ADC FAULT
ON/OFF
24V FAULT
ON/OFF
FLASH FAULT
ON/OFF
RAM FAULT
ON/OFF
WDT FAULT
ON/OFF
12V FAULT
ON/OFF
5V FAULT
ON/OFF
3V FAULT
ON/OFF
INPUT LOOP FAULT
ON/OFF
LON CONFIG
HGH ALARM LEVEL
XX.XX
LOW ALARM LEVEL
XX.XX
CAL GAS CONC
XX.XX
STATUS RATE
XXX
LON ADDRESS
XXX
6901 WEST 110TH STREET
MINNEAPOLIS, MN 55438
USA
GENERAL OPTIONS
TAG
XXXXX
DESCRIPTOR
XXXXX
MESSAGE
XXXX
FINAL ASSY NUM
XXXX
LON FAULT
INVALID CONFIG
ON/OFF
LON OFFLINE
ON/OFF
TERM BD FAULT
ON/OFF
BACKLIGHT CTRL
OFF
ON
AUTOMATIC
HART OPTION
TAG
XXXXX
DESCRIPTOR
XXXXX
MESSAGE
XXXX
FINAL ASSY NUM
XXXX
DEVICE OPTION
GAS NAME
XXXX
UNIT OF MEASURE
URV
XXXX
LRV
XXXX
USL
XXXX
LSL
XXXX
RTC
SYNC W/DISP
SECONDS
XX
MINUTES
XX
HOURS
XX
DAY
XX
MONTH
XX
YEAR
XX
UNIT OF MEASURE
PPM
%
MGM3
17-Aug-11
GT3000
3.25
Detector Electronics
