Руководство пользователя
14. Настройка DDM
110
www.qtech.ru
-------------- ----------- ----------- ---------- ---------
Temperature(°С)
33
70
0
70
0
Voltage(V)
7.31(A+) 5.00
0.00 5.00 0.00
Bias current(mA)
6.11(W+) 10.30
0.00
5.00
0.00
RX Power(dBM)
-30.54(A-) 9.00 -25.00
9.00 -25.00
TX Power(dBM)
-13.01(A-) 9.00 -12.00(-25.00)
9.00
-
10.00(-25.00)
Пример 3:
Ethernet 21 включен в оптический модуль с DDM. Включение мониторинга трансивера на
порте, после просмотра мониторинга на оптическом модуле.
Шаг 1: Просмотр мониторинга трансивера на оптическом модуле. На Еthernet 21 и
ethernet 22 не включен мониторинг трансивера, установленный интервал 30 минут.
Switch(config)#show transceiver threshold-violation interface ethernet
1/21-22
Ethernet 1/21 transceiver threshold-violation information:
Transceiver monitor is disabled. Monitor interval is set to 30
minutes.
The last threshold-violation doesn’t exist.
Ethernet 1/22 transceiver threshold-violation information:
Transceiver monitor is disabled. Monitor interval is set to 30
minutes.
The last threshold-violation doesn’t exist.
Шаг 2: Включение мониторинга трансивера на ethernet 21.
Switch(config)#interface ethernet 1/21
Switch(config-if-ethernet1/21)#transceiver-monitoring enable
Шаг 3: Просмотр мониторинга трансивера на оптическом модуле. В следующих
настройках, на ethernet 21 включен мониторинг трансивера, последнее нарушение
порогового значения Jan 02 11:00:50 2011, подробная информация о DDM, превышающая
пороговое значение также показана:
Switch(config-if-ethernet1/21)#quit
Switch(config)#show transceiver threshold-violation interface ethernet
1/21-22
Ethernet 1/21 transceiver threshold-violation information:
Transceiver monitor is enabled. Monitor interval is set to 30 minutes.
