12
REmOVinG thE CYBEX PALLAS-fiX
Perform all installation steps in reverse order.
Note! By following these steps the vehicle’s seat pad will be protected and the iSOfiX
connectors will be prevented from being stained or damaged. Damages and stains could
obstruct a smooth operation.
– Release the ISOFIX connectors (o) by simultaneously pulling and slinging
back the red release buttons (y).
– Pull the child seat out of the ISOFIX-CONNECT guides (u).
– Rotate the connectors (o) by 180°.
– Pull the adjusting handle (c) located on the main frame (w) of the CYBEX PALLAS-fix
and push the connectors (o) into the child seat until they are completely hidden.
SECURING THE CHILD
Note! It is possible that some car seats that are made of soft material (e.g. velours,
leather, etc.) may show signs of usage and/or discolouration. In order to avoid this, you
could, for example, place a cover or towel underneath it. In this context, we would also like
to refer to you to our cleaning instructions, which must absolutely be followed before the
first use of the seat.
Place the CYBEX PallaS-fix on the respective seat in the car.
– Please make sure that the backrest (a) of the CYBEX PALLAS-fix rests flat against the
backrest of the car seat so that the child seat is under no circumstance in a sleeping
position.
– When using the ISOFIX anchorage points (j) in the car, make sure that the
backrest (a) of the CYBEX PALLAS-fix is perfectly aligned and in full contact
with the upright part backrest of the car seat. The position can be adjusted
with the adjusting handle (c) located under the seat cushion (d) on the main
frame (w) of the child seat.
– Should the headrest of the vehicle seat interfere, please pull it out completely, turn
it around or take it off entirely (exceptional case, refer to the section “THE BEST
POSITION IN THE CAR“). The backrest (a) optimally adjusts to almost any inclination
of the vehicle seat.
Warning! the backrest of the CYBEX PALLAS-fix should rest flat against backrest
of the car seat. Pushing the booster rearwards the seat should be tightly pressed
against the seat. for the best possible protection of your child, the seat must be in a
normal upright position!
