inStALLinG Of thE ChiLd SEAt With thE iSOfiX-COnnECt SYStEm
The safety of your child will be increased using the iSOfiX-CONNECT system
linking the CYBEX PallaS-fix tightly with the vehicle. Your child will still be
buckled up using the car’s three-point belt.
Note! The car’s ISOFIX anchorage points (j) are two metal rings per seat, located
between the backrest and the seat cushion of your vehicle seat. if in doubt please refer to
your vehicle owner’s manual.
Note! Make sure that the green safety indication (b) of the connectors is not visible. If
necessary, release them by pushing and simultaneously pulling back the red release
button (y). Repeat this procedure with the other connector.
Note! For additional information please refer to the section “SECURING THE CHILD“.
– Push both of the connectors (o) into the ISOFIX-CONNECT guides (u) until you hear
them clicking into the ISOFIX anchorage points (j).
– Make sure that the CYBEX PALLAS-fix is connected properly by trying to pull the child
seat out.
– The green safety indication (b) must be clearly visible on both sides of the red release
buttons (y).
– With the adjusting handle (c), located on the main frame (w) of the CYBEX PALLAS-fix,
you can now adjust the position of the child seat.
– You can now buckle up the child. Please refer to section “SECURING WITH SAFETY
CUSHION“.
– Connect the two enclosed ISOFIX-CONNECT guides (u) (longer parts pointing upward)
with the ISOFIX anchorage points (j). An opposite installation (longer parts pointing
downward) is also possible.
– Pull the adjusting handle (c), located under the seat cushion (d) on main frame (w) of
the CYBEX PallaS-fix.
– Pull the connectors (o) as far out as they will go.
– Rotate the connectors (o) by 180° until they point into the direction of the ISOFIX-
CONNECT guides (u).
