�u�ntize
Позволяет подкорректировать длительность запи-
санных вами нот. например, если записанная вами
композиция слегка несинхронна в отдельных местах,
вы можете подкорректировать ноты на 1/8 или на
1/16. Изменения, сделанные с помощью параметра
�uantize
влияют на всю песню.
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
меняет размер колебания
выбирает ноты, длительность
которых вы хотите изменить.
Установки разбивания на группы по дли-
тельности (согласно длительности ноты):
четвертная
одна восьмая
триоль из восьмых нот
одна шестнадцатая
триоль из шестнадцатых нот
Если для корректировки вы выберете 1/8 или 1/16,
будет отображаться параметр размера колебания в
процентах. Изменение размера колебания сделает
звучание песни более живым и придаст ей ощуще-
ния исполнения в стиле джаз или свинг.
диапазон установки: 0% – 100%
Если вы выберете для корректировки «/»
Ваша игра на клавиатуре
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
Размер колебания = 50%, без колебания, ровная
мелодия
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
Размер колебания = 75% (51 % и выше): интервал
периодического ритма слегка растянут
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
Размер колебания = 25% (49 % и меньше): интервал
периодического ритма слегка ускорен
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
Размер колебания = 67%: интервал периодического
ритма передвинут на третий бит триоли.
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
Установка по умолчанию: off
�uick Pl���
Позволяет определить, должна ли песня, начинающа-
яся не в точке первого бита первого такта, проигры-
ваться с первой ноты или с начала песни (некоторые
песни начинаются не с нотных данных. Этот пара-
метр позволяет пропустить эти настройки и начать
воспроизведение с первой ноты. Также с помощью
этого параметра можно пропускать паузы, которые
обычно случаются перед затактовой нотой).
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
Настройки:
On
воспроизведение с первой ноты
Off
воспроизведение с начала песни (в том
числе и пауз)
Настройка по умолчанию: on
Ch�nnel Listen
Позволяет вам выбирать и прослушивать записанное
содержимое одного канала. Воспроизведение начина-
ется с первой ноты.
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
диапазон настройки: Ch 1 – Ch 16
Настройка по умолчанию: Ch 1
ПРИМЕЧАНИЕ
данные песни содержат 16 каналов. каж-
дая инструментальная партия назначает-
ся отдельному каналу, поэтому для этого
инструмента слова «канал� и «звуковая
дорожка� имеют одинаковое значение.
ПРИМЕЧАНИЕ
каналы, не содержащие данных, не отоб-
ражаются. Однако для некоторых песен
могут отображаться все каналы (в том
числе и не содержащие данных).
Ch�nnel Cle��
Позволяет удалить данные с одного из 16 каналов,
или со всех каналов сразу.
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
диапазон настройки: Ch 1 – Ch 16, ALL (все каналы)
Установка по умолчанию: Ch 1
Параметры
Settings for Song Recording and Playback—Song Settings
CP300 Owner’s Manual
86
Ref
erence
Parameters
This allows you to correct the timing of notes you’ve
recorded. For example, if the timing of your performance
was slightly off in places, you can adjust the notes to precise
eighth or sixteenth notes. Changes made in Quantize affect
the entire Song.
Quantize timing settings (according to note value):
Off
If you select “1/8” or “1/16” for correction, the Swing Rate
parameter is shown (as a percentage value). Changing the
Swing Rate will make the Song sound more lively and give it
more of a swing or jazzy feel.
Setting range: 0% – 100%
If you select “1/8” for correction:
Default setting: Off
This allows you to specify whether a Song that starts at a
point other than the first beat of the first measure should be
played from the first actual note or from the beginning of
the Song. (Some Songs are recorded with initial settings and
non-note data at the very beginning of the Song; this
parameter allows you to skip those settings and play the
Song from the first note. It also allows you to skip over rests
that naturally occur before the pickup note in a Song.)
Settings:
Default setting: On
This allows you to select and audition the recorded contents
of a single channel. Playback starts from the first note.
Setting range: Ch 1 – Ch 16
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
n Channels that do not contain any data are not displayed.
However, for some Songs, all channels (including the
channels that contain no data) may be displayed.
This allows you to delete data of a single specified channel,
or of all 16 channels at once.
Setting range: Ch 1 – Ch 16, ALL (all channels)
Default setting: Ch 1
n Song data consists of 16 channels. Each instrument part is
assigned to a specific channel, so for this instrument, the
words “channel” and “track” have the same meaning.
Quantize
Quantize Execute?-->
SwingRate= 50% 1/8
NO
YES
A
B
D
C
Changes the swing rate
Selects the notes for which
you can adjust the timing
1/4 .............
1/8 .............
1/12 ...........
1/16 ...........
1/24 ...........
Quarter note
Eighth note
Eighth note triplets
Sixteenth note
Sixteenth note triplets
Your keyboard performance
Swing rate = 50%: No swing; straight
Swing rate = 75% (51% or higher): The timing of even beat
notes is slightly delayed.
Swing rate = 25% (49% or lower): The timing of even beat notes
is slightly early.
Swing rate = 67%: The timing of even beat notes is moved to
the third beat of the triplets.
Quick Play
On
Playback from the first note
Off
Playback from the start of the Song (including a rest
or blank measure)
Channel Listen
Channel Clear
QuickPlay
On
NO
YES
A
B
D
C
ChannelListen Start?-->
Ch1
NO
YES
A
B
D
C
ChannelClear Execute?-->
Ch1
NO
YES
A
B
D
C
Настройки для записи и воспроизведения песни – настройки песни (Song Settings)
