Yamaha CP300 - Инструкция (Страница 53)

Руководство пользователя CP300 3
Control Names and Functions
Справочная информация
Настройки Мастер-режима-
Мастер-редактирования
мастер-режим позволяет разделить клавиатуру на 4 независимых части (зоны), которые можно задейс-
твовать, когда светится кнопка [MASTER] .
ПРИМЕЧАНИЕ
эта установка сохраняется даже после того, как вы выключите инструмент. если вы отклю-
чите настройку использования резервной памяти в мастер-режиме в меню других настроек,
настройки мастер-режима сбросятся до настроек по умолчанию, когда вы включите инстру-
мент в следующий раз.
Master Settings—Master Edit
CP300 Owner’s Manual
53
Ref
erence
Reference Section
Master Settings—Master Edit
The Master mode allows you to divide the keyboard into up to four independent areas (zones) which will be effective when
the [MASTER] button is turned on.
n This setting is retained even after you turn off the power to the CP300. If you set the Memory Backup’s Master Setting to Off in the
Other Settings menu, the Master Settings will return to the default (initial) values when you turn on the power next time (page 71).
1
Press the [MASTER EDIT] button to call up the Master Setting display.
2
Select the desired item by pressing the [MASTER EDIT] button or by using the A [–]
[+] buttons.
For information about the parameters and their values, refer to “Parameters” on page 54.
3
Use the C [–][+] buttons to select a target item.
4
Use the D [–][+] buttons to change the value.
5
Press the [EXIT] button to exit the Master Setting display and return to normal play.
NO YES
EXIT
MASTER PERFORMANCE
MASTER EDIT PERFORM.FILE
TRANSPOSE
SONG SELECT
NEW SONG
REC STOP PLAY/PAUSE
SYNCHRO START
SONG VOICE/PERFORMANCE
1 2 3-16
TRACK
SONG FILE
SONG SETTING
MIDI OUT PANEL LOCK
DOWN UP
TEMPO
A B
D C
CONTRAST GRAND PIANO 1 GRAND PIANO 2 MONO PIANO E. PIANO 1 E. PIANO 2 E. PIANO 3 CLAVI. VIBES
ORGAN 1 ORGAN 2 HARPSI. STRINGS CHOIR/PAD GUITAR BASS XG
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
VOICE EDIT SPLIT
VARIATION
REVERB CHORUS SPEAKER MIDI SETTING
MASTER EQ EDIT CLICK OTHER SETTING DEMO
2
3 4 1, 2 5
Slider
Zone1 Volume
NO YES
A B
D C
1
Нажмите кнопку �M�S��� �DI��, чтобы взывать меню M�ste� Setting
Master Settings—Master Edit
CP300 Owner’s Manual
53
Ref
erence
Reference Section
Master Settings—Master Edit
The Master mode allows you to divide the keyboard into up to four independent areas (zones) which will be effective when
the [MASTER] button is turned on.
n This setting is retained even after you turn off the power to the CP300. If you set the Memory Backup’s Master Setting to Off in the
Other Settings menu, the Master Settings will return to the default (initial) values when you turn on the power next time (page 71).
1
Press the [MASTER EDIT] button to call up the Master Setting display.
2
Select the desired item by pressing the [MASTER EDIT] button or by using the A [–]
[+] buttons.
For information about the parameters and their values, refer to “Parameters” on page 54.
3
Use the C [–][+] buttons to select a target item.
4
Use the D [–][+] buttons to change the value.
5
Press the [EXIT] button to exit the Master Setting display and return to normal play.
NO YES
EXIT
MASTER PERFORMANCE
MASTER EDIT PERFORM.FILE
TRANSPOSE
SONG SELECT
NEW SONG
REC STOP PLAY/PAUSE
SYNCHRO START
SONG VOICE/PERFORMANCE
1 2 3-16
TRACK
SONG FILE
SONG SETTING
MIDI OUT PANEL LOCK
DOWN UP
TEMPO
A B
D C
CONTRAST GRAND PIANO 1 GRAND PIANO 2 MONO PIANO E. PIANO 1 E. PIANO 2 E. PIANO 3 CLAVI. VIBES
ORGAN 1 ORGAN 2 HARPSI. STRINGS CHOIR/PAD GUITAR BASS XG
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
VOICE EDIT SPLIT
VARIATION
REVERB CHORUS SPEAKER MIDI SETTING
MASTER EQ EDIT CLICK OTHER SETTING DEMO
2
3 4 1, 2 5
Slider
Zone1 Volume
NO YES
A B
D C
2
Выберите нужный раздел с помощью кнопки �M�S��� �DI�� или кнопок � �–� �+�
Информацию об этих параметрах и их значениях ищите на стр. 54
�
С помощью кнопок C �–��+� выберите нужный раздел
4
С помощью кнопок D �–��+� измените значение
5
Нажмите кнопку ��XI��, чтобы выйти из меню M�ste� Setting и вернуться к обыч-
ной игре
