Yamaha CP300 - Инструкция (Страница 67)

Руководство пользователя CP300
Различные настройки инструмента –
другие настройки
В меню других настроек можно найти различные настройки, которые в основном относятся к общему звучанию
и управлению инструментом. среди них детальные настройки реакции инструмента на прикосновение к клави-
шам, настройки, управления с помощью педали и другие.
ПРИМЕЧАНИЕ
отредактированное меню других настроек будет удалено после того, как вы выключите инструмент.
если вы включите функцию Memor�� Backup’s �ther Setting в меню других настроек, текущие зна-
чения других настроек останутся в силе, когда вы выключите и снова включите инструмент (стр.��1)
другие настройки – основные действия
CP300 Owner’s Manual 67
Ref
erence
Miscellaneous CP300 Settings—Other Settings
The Other Setting(s) menu provides a variety of settings, generally related to the overall sound and operation of the CP300.
These include detailed settings for touch response, tuning, pedal operation, and more.
n The edited Other Settings will be erased after you turn off the power to the CP300. If you set the Memory Backup’s Other Setting
to On in the Other Settings menu, the current Other Settings’ values will remain in effect when you turn the power off and back on
again (page 71).
1
Press the [OTHER SETTING] button to call up the Other Settings menu.
2
Select the desired item by pressing the [OTHER SETTING] button or by using the
A [–][+] buttons.
For information about the parameters and their values, refer to “Parameters” on page 68.
3
Use the C [–][+] buttons to select a target item.
4
Use the D [–][+] buttons to change the value.
Press the [–][+] buttons simultaneously to instantly reset to the default setting.
5
Press the B [+ (YES)] button to execute the job (if an “Execute?” message appears).
Pressing the B [+ (YES)] button calls up a confirmation prompt (“Sure?”). Press the B [+ (YES)] button
again to execute the job. An “Executing” message appears and the data is saved. When the operation is
complete, a “Completed” message appears briefly, then returns to the previous display.
To cancel the operation, press the B [– (NO)] button instead of the B [+ (YES)] button.
6
Press the [EXIT] button to exit from the Other Settings menu.
Other Settings—Basic Operation
NO YES
EXIT
MASTER PERFORMANCE
MASTER EDIT PERFORM.FILE
TRANSPOSE
SONG SELECT
NEW SONG
REC STOP PLAY/PAUSE
SYNCHRO START
SONG VOICE/PERFORMANCE
1 2 3-16
TRACK SONG FILE
SONG SETTING
MIDI OUT PANEL LOCK
DOWN UP
TEMPO
A B
D C
CONTRAST GRAND PIANO 1 GRAND PIANO 2 MONO PIANO E. PIANO 1 E. PIANO 2 E. PIANO 3 CLAVI. VIBES
ORGAN 1 ORGAN 2 HARPSI. STRINGS CHOIR/PAD GUITAR BASS XG 1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
VOICE EDIT SPLIT
VARIATION
REVERB CHORUS SPEAKER MIDI SETTING
MASTER EQ EDIT CLICK OTHER SETTING DEMO
1, 2
2 5
3 4 6
Transpose
Song 0
NO YES
A B
D C
FactorySet Sure?-->
MemoryFileExcluded
NO YES
A B
D C
1
Нажмите кнопку ���H�� S���I�G�, чтобы вызвать меню других настроек.
2
С помощью кнопки ���H�� S���I�G� или кнопок � �–��+� выберите необходимый
параметр.
Информацию о параметрах и их значениях можно найти в главе «Параметры� на стр. 68.
3
С помощью кнопок C �–��+� выберите нужный пункт
4
С помощью кнопок D �–��+� измените значение
Одновременно нажмите кнопки –] [+] , чтобы сбросить настройки до настроек по умолчанию.
CP300 Owner’s Manual
67
Ref
erence
Miscellaneous CP300 Settings—Other Settings
The Other Setting(s) menu provides a variety of settings, generally related to the overall sound and operation of the CP300.
These include detailed settings for touch response, tuning, pedal operation, and more.
n The edited Other Settings will be erased after you turn off the power to the CP300. If you set the Memory Backup’s Other Setting
to On in the Other Settings menu, the current Other Settings’ values will remain in effect when you turn the power off and back on
again (page 71).
1
Press the [OTHER SETTING] button to call up the Other Settings menu.
2
Select the desired item by pressing the [OTHER SETTING] button or by using the
A [–][+] buttons.
For information about the parameters and their values, refer to “Parameters” on page 68.
3
Use the C [–][+] buttons to select a target item.
4
Use the D [–][+] buttons to change the value.
Press the [–][+] buttons simultaneously to instantly reset to the default setting.
5
Press the B [+ (YES)] button to execute the job (if an “Execute?” message appears).
Pressing the B [+ (YES)] button calls up a confirmation prompt (“Sure?”). Press the B [+ (YES)] button
again to execute the job. An “Executing” message appears and the data is saved. When the operation is
complete, a “Completed” message appears briefly, then returns to the previous display.
To cancel the operation, press the B [– (NO)] button instead of the B [+ (YES)] button.
6
Press the [EXIT] button to exit from the Other Settings menu.
Other Settings—Basic Operation
NO YES
EXIT
MASTER PERFORMANCE
MASTER EDIT PERFORM.FILE
TRANSPOSE
SONG SELECT
NEW SONG
REC STOP PLAY/PAUSE
SYNCHRO START
SONG VOICE/PERFORMANCE
1 2 3-16
TRACK SONG FILE
SONG SETTING
MIDI OUT PANEL LOCK
DOWN UP
TEMPO
A B
D C
CONTRAST GRAND PIANO 1 GRAND PIANO 2 MONO PIANO E. PIANO 1 E. PIANO 2 E. PIANO 3 CLAVI. VIBES
ORGAN 1 ORGAN 2 HARPSI. STRINGS CHOIR/PAD GUITAR BASS XG
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
VOICE EDIT SPLIT
VARIATION
REVERB CHORUS SPEAKER MIDI SETTING
MASTER EQ EDIT CLICK OTHER SETTING DEMO
1, 2
2 5
3 4 6
Transpose
Song 0
NO YES
A B
D C
FactorySet Sure?-->
MemoryFileExcluded
NO YES
A B
D C
5
Нажмите кнопку � �+ (��S)�, чтобы выполнить действие, если на дисплее появит-
ся сообщение “St��t?”
нажмите кнопку B [+ (Y�S)], чтобы вызвать подтверждающую подсказку (“Sure?”). ещё раз
нажмите кнопку B [+ (Y�S)], чтобы выполнить действие. на дисплее появится сообщение
“�xecuting” и данные сохранятся. когда операция завершится, на недолгое время появится сооб-
щение “�ompleted” и затем дисплей вернётся в предыдущее состояние. Чтобы отменить операцию,
нажмите кнопку B [– (N�)] вместо B [+ (Y�S)].
CP300 Owner’s Manual
67
Ref
erence
Miscellaneous CP300 Settings—Other Settings
The Other Setting(s) menu provides a variety of settings, generally related to the overall sound and operation of the CP300.
These include detailed settings for touch response, tuning, pedal operation, and more.
n The edited Other Settings will be erased after you turn off the power to the CP300. If you set the Memory Backup’s Other Setting
to On in the Other Settings menu, the current Other Settings’ values will remain in effect when you turn the power off and back on
again (page 71).
1
Press the [OTHER SETTING] button to call up the Other Settings menu.
2
Select the desired item by pressing the [OTHER SETTING] button or by using the
A [–][+] buttons.
For information about the parameters and their values, refer to “Parameters” on page 68.
3
Use the C [–][+] buttons to select a target item.
4
Use the D [–][+] buttons to change the value.
Press the [–][+] buttons simultaneously to instantly reset to the default setting.
5
Press the B [+ (YES)] button to execute the job (if an “Execute?” message appears).
Pressing the B [+ (YES)] button calls up a confirmation prompt (“Sure?”). Press the B [+ (YES)] button
again to execute the job. An “Executing” message appears and the data is saved. When the operation is
complete, a “Completed” message appears briefly, then returns to the previous display.
To cancel the operation, press the B [– (NO)] button instead of the B [+ (YES)] button.
6
Press the [EXIT] button to exit from the Other Settings menu.
Other Settings—Basic Operation
NO YES
EXIT
MASTER PERFORMANCE
MASTER EDIT PERFORM.FILE
TRANSPOSE
SONG SELECT
NEW SONG
REC STOP PLAY/PAUSE
SYNCHRO START
SONG VOICE/PERFORMANCE
1 2 3-16
TRACK
SONG FILE
SONG SETTING
MIDI OUT PANEL LOCK
DOWN UP
TEMPO
A B
D C
CONTRAST GRAND PIANO 1 GRAND PIANO 2 MONO PIANO E. PIANO 1 E. PIANO 2 E. PIANO 3 CLAVI. VIBES
ORGAN 1 ORGAN 2 HARPSI. STRINGS CHOIR/PAD GUITAR BASS XG
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
VOICE EDIT SPLIT
VARIATION
REVERB CHORUS SPEAKER MIDI SETTING
MASTER EQ EDIT CLICK OTHER SETTING DEMO
1, 2
2 5
3 4 6
Transpose
Song 0
NO YES
A B
D C
FactorySet Sure?-->
MemoryFileExcluded
NO YES
A B
D C
6
Нажмите кнопку ��XI��, чтобы выйти из меню настроек MIDI. MIDI..
