ADJUSTING OF THE MINIMUM
OF THE TOP BURNERS
The burners in the cooktop are fitted
with safety valves; the minimum flame
regulation screw is located on the out-
side of the gas tap (fig. 8.6).
In passing from one type of gas to anoth-
er, the gas flow must also be changed,
considering that in this position the flame
must have a length of about 4 mm and
must remain lit even with a brusque pas-
sage from the maximum position to that
of minimum.
The flame adjustment is done in the fol-
lowing way:
– Turn on the burner
– Turn the tap to the MINIMUM position
– Take off the knob
– With a thin screwdriver pass by the
hole of microswitch and turn the screw
F until adjustment is correct (fig. 8.6).
Normally for G 30/G 31, tighten up the
regulation screw.
F
Fig. 8.6
