Fig. 2.3
CHOICE OF THE BURNER
On the control panel, near every knob,
there is a diagram that indicates which
burner is controlled by that knob.
The suitable burner must be chosen
according to the diameter and the
capacity used.
As an indication, the burners and the
pots must be used in the following
way:
It is important that the diameter of the
pot be suitable to the potentiality of the
burner so as not to compromise the high
output of the burners and therefore ener-
gy waste.
A small pot on a large burner does not
give you a boiling point in a shorten
amount of time since the capacity of heat
absorption of a liquid mass depends on
the volume and the surface of the pot.
DIAMETERS OF PANS WHICH MAY BE
USED ON THE HOBS
BURNERS
MINIMUM
MAX.
Auxiliary
12 cm
14 cm
Semirapid
16 cm
24 cm
Rapid
24 cm
26 cm
Triple-ring
26 cm
28 cm
do not use pans with concave or convex bases
GRATE FOR SMALL PANS
This grate is to be placed on top of the
(smaller) auxiliary burner when using
small diameter pans, in order to prevent
them from tipping over.
Fig. 2.4
