12
THERMOSTAT GRADE TABLE
Thermostat Oven
indicator temperature
1 150 °C
2 165 °C
3 180 °C
4 195 °C
5 210 °C
6 225 °C
7 240 °C
8 255 °C
9 270 °C
285 °C
Fig. 3.1
GAS OVEN - TG.. 664 GHI , PG.. 664 GGHI
3
Attention: the oven door becomes
very hot during operation.
Keep children away.
(Models with glass lid)
Attention:
The cooker lid must be kept open
when the gas oven is in use.
GENERAL FEATURES
The cooker is furnished completely
clean; it is advisable, however, upon first
use, to turn the oven on to the maximum
temperature (position ) to eliminate
possible traces of grease from the oven
burner.
The gas oven is provided with:
– One gas burner (3700 W), located at
the bottom, providing safety device
and automatic ignition.
– One gas grill (2500 W), placed on the
top, providing self-ignition and safety
device.
WARNING:
The door is hot, use the handle.
During use the appliance becomes
hot. Care should be taken to avoid
touching heating elements inside the
oven.
OVEN BURNER
It carries out normal “oven cooking”.
The gas flow to the burner is regulated
by a thermostat which allow to maintain
the oven temperature constant.
The control of the temperature is assured
by a thermostatic probe positioned inside
the oven.
The probe must be always kept in its
housing, in a clean condition, as an
incorrect position or encrustment may
cause an alteration in the control of the
temperature.
Moreover, the thermostat is fitted with a
safety valve which automatically shuts off
the gas supply when the flame goes out.
THERMOSTAT
The numbers 1 to 10 printed on the knob
(fig. 3.1) indicate the increasing oven
temperature value (see table below).
The temperature is constantly maintained
on the set value.
Symbol near position 10 indicates that
the electric ignition is incorporated in the
knob and is activated by the knob itself.
