DeLonghi TGX 664GHI - Инструкция (Страница 17)

17
Fig. 3.9
Fig. 3.7
USE OF THE ROTISSERIE
PG.. 664 GGHI - (fig. 3.7):
– Insert the tray into the lowest rack
holders of the oven and insert the
rod support into the intermediate rack
holders.
– Put the meat to be cooked onto the
rod, being careful to secure it in the
center with the special forks.
– Insert the rod into the motor opening
and rest it onto the support of the spit
collar; then remove the grip by turning
it to the left.
– Fit the heat shield and switch on the
grill and turnspit.
The rotation direction of the rotisser-
ie can be either clokwise or counter-
clockwise.
Very important: the rotisserie must
always be used with the oven door
ajar and with shield “A” mounted.
Attention: the oven door becomes
very hot during operation.
Keep children away.
It is recommended that you do not
grill for longer than 30 minutes at any
one time.
Fig. 3.8
OVEN LIGHT
The cooker is equipped with a light that
illuminates the oven to enable visually
controlling the food that is cooking.
Models with switch knob
( PG.. 664 GGHI )
To light the oven lamp turn the knob fig.
fig. 3.8, to the symbol .
Models with push button
( TG.. 664 GHI )
The oven lamp is operated by pressing
the relative push button (fig. 3.9).
