Before you install, En gl ish – Инструкция по эксплуатации Kastor K0-20 Wood-burning sauna stoves
Страница 37
EN
gl
ISH
1.
1.1.
1.2.
1.3.
1. bEfOrE YOU INSTAll
Inspect both product and the contents of the package as soon
as you receive them. Report any transport damages to the
deliverer.
1.1. PACKAGE CONTENTS AND ITS INSPECTION
The stove package contains:
The stove
•
Within the fire compartment
•
– Installation instructions
– Grate
– Air guide plate
– Connection pipe
– 4 adjustment legs
– Door handle. (Attachment screws and washers come
attached to the stove door)
Two steel caps (one on the foremost sweeping hole and
•
another on the back wall flue hole, which bolted into place
with a screw driven through the intermediate mantle).
If the separately installable water container package VK-20 has
been ordered, it comes in its own package.
1.2. IMPORTANT MATTERS AND REGULATIONS
During installation and use these instructions and all relevant
official regulations must be followed. The sauna stove must
not be used for any other purposes such as drying clothes,
heavy heating during building etc. The stove must also never
be covered in any way during use or when it is warm.
Also check the following aspects and their influence on your
choice of stove installation location:
Safety distances to flammable and non-flammable structu-
•
res (Picture 2.3. and 2.4.)
Location of chimney connection (height from floor of any
•
existing chimney connection or installation route of any
new chimney pipe)
Floor material (flammable, non-flammable, tiled and water-
•
proofed)
1.3. INSTALLATION OF WATER TANK VK-20
The water tank package is installed according to instructions
that come with its own package. Attach it to the sauna stove
before the burn-in to ensure the removal of any fumes that
might come off the water tank and the hardening of the flame-
proof paint on the front panel.
picture 1.2. Safety distances.
Measurements in millimetres.
