mm"
1
mm -
(#ii/i;®liAii?L)
VIDEO OUT ^ VIDEO IN (fOft)
AUDIO OUT --------» AUDIO IN (1
j
M)
3
m
[CAMERA/OFF/VCR]
iiiSiSaffi
[VCR] °
• |VCR| igTfVS O SiB "
4
(-»es)
Watching Playback on a TV
By connecting the Movie Camera to a TV, you can watch
playback of the recorded scenes on the TV screen.
Before connecting, turn off both the Movie Camera and the TV
for safety’s sake.
1
Use the AV Cable (supplied) to connect the
Movie Camera with the TV.
Movie Camera
TV (AV Input Sockets)
VIDEO OUT --------------- > VIDEO IN
AUDIO OUT ---------------> AUDIO IN
2
Select the channel on the TV which
corresponds to the video/audio input sockets
used for connecting.
(Refer to the operating instructions of your TV.)
3
Set the [CAMERA/OFFA/CR] Switch to [VCR].
• The [VCR] Lamp Q lights.
4
start playback on the Movie Camera. (-»
68
)
