29 Video Output Socket [@] (-* 72, 144)
30 Audio Output Socket [®] (-♦ 72,144)
31 Finder (-♦ 48, 80)
Due to limitations in LCD production technology, there
may be some tiny bright or dark spots on the Finder
screen, the whole screen may have a slight colour cast,
and flickering may occur. Flowever, this is not a
malfunction and does not affect the recorded picture.
32 Cover of the Button-type Battery's Compartment
[BACKUP BATTERY] (-♦ 52)
33 DC Input Socket [DC IN] (-* 18)
34 Battery Eject Lever [O BATTERY EJECT] (-* 24)
35 Recording Start/Stop Buttons (-* 56, 58)
Use either of these buttons depending on the recording
angle.
36 Off/On Mode Selector Switch [CAMERA/OFFA/CR]
(-♦ 24, 58, 68, 80)
37 Grip Belt (-* 48)
38 Speaker (-* 68)
39 Cassette Eject Buttons [^ EJECT] (-* 42)
40 Date/Time/Title Button [DATE/TITLE] (-* 56, 130)
41 Zoom Lever [W7T] (-* 64, 92)
Volume Adjustment Lever [—VOL-F] (-♦ 68)
42 Eyepiece Corrector Lever (-♦ 48)
43 Shoulder Strap Flolders (-♦ 50)
44 Tripod Receptacle
45 Lens Cap (-* 48, 106)
46 Lens Cap Holder (-* 48)
