^mmm
1. 5t;?i$#ggg (Pfl№)
• " (-» 20)
2
.
(-» 20)
3.
(SISHd№)
• (iJA-itnilii-teffliailiilS “
1
[DC
IN]
ffi?L
»
2
[DC OUT]
m
?L»
itx)-- 24ov ■
e>()/6i )Mz) ’ W lU ii -M '& [i :<?: ft ffl B-'f th fa -M № ii fnf - [ m -S ® yi|
ENGLISH
The 3 Types of Power Supplies
To try out the Movie Camera at home, we recommend that
you use the AC Adaptor Q-
1. AC Adaptor (supplied)
• To use the Movie Camera indoors.
• To charge the Battery. (-♦ 20)
2. Battery (supplied)
• To use the Movie Camera outdoors, and also indoors
when there is no AC mains socket nearby. (-» 20)
3. Car Battery Charger (optional)
•To use the Movie Camera in a car.
Using the AC Adaptor as Power Supply Unit
1
Connect the DC Input Lead to the [DC IN]
Socket on the Movie Camera.
2
Connect the other end of the cable to the
[DC OUT] Socket on the AC Adaptor.
3
Connect the AC Mains Lead to the AC Adaptor
and to an AC mains socket.
The AC Adaptor features automatic universal voltage
adjustment (AC 100-240 V, 50/60 Hz), therefore, there is no
need for any manual voltage adjustment for use in other
countries.
18
