Страница 37: Inserting the cassette
Внимание! Текст в этом документе был распознан автоматически. Для просмотра оригинальной страницы Вы можете воспользоваться режимом "Оригинал".
mAmmmm
1
- (-»18,24)
2
mm^m o ’ Mmmm^ °
3
[A
OPEN] ’
I^B^$PS
u
SÌ№
te
’
t
I§;<2^
м
М
90° °
•
■
j
S
ì
* ■ wmMimmm
4
EJECT](}I№) a°
5
©ffi]5'h ’ H^KÌliiJ
Il °
6
'
mmm
[
lock
]
m -
•
■ afflinsjatiaiisEPn]
• tntiBEAsgsxtbisa^a »
• aaSSaaAfPtRaSSiPt = ftnliiE#?<A{aa«flAtn
t» »
• 5n*}fhAì*AXanB|Ki№A?tM A A A * ’ ![^! Ìi^jBAAlS »
A ; A EJECT] (A A) ffl ’ A A A A A A * =
A
ìl
OCKI
a
' glPSAAAA “
Inserting the Cassette
1
Connect the AC Adaptor or attach a charged
Battery. (-»18, 24)
2
Turn the cog wheel
Q
tighten the tape.
3
Slide the
[A
OPEN] Lever to the left and
simultaneously open the LCD Monitor in the
direction of the arrow approximately 90°.
• Be sure to keep the LCD Monitor in its vertical position,
so that the Cassette Compartment Cover, when it
opens, does not hit the LCD Monitor.
4
Push the
[A
EJECT] Button.
5
Insert the cassette with the cassette window Q
facing outward and push it all the way in.
S
Close the Cassette Compartment by pressing
the [LOCK] Button.
• If the AC Adaptor or Battery is used to supply power, it is
possible to insert or eject the cassette without turning on the
Movie Camera.
• It is not possible to take out the cassette during recording.
• Do not insert and take out the cassette repeatedly. This
could cause the tape to become loose or damaged.
• If a cassette with broken out erasure prevention tab is
inserted, the [Elgl] Indication flashes.
Ejecting the Cassette
Push the [A EJECT] Button and pull out the cassette.
Close the Cassette Compartment by pressing the [LOCK]
Button.
42
