ENGLISH
Adjusting the Brightness and Colour
Level of the LCD Monitor/Finder
If you select the [LCD/EVF SETUP] Sub-Menu of the [VCR
FUNCTIONS] or the [CAMERA FUNCTIONS] Main-Menu, the
following items are displayed.
LCD Brightness [LCD BRIGHTNESS]
To adjust the brightness of the picture on the LCD screen.
LCD Colour Level [LCD COLOUR]
To adjust the colour saturation of the picture on the LCD screen.
Finder Brightness [EVF BRIGHTNESS]
To adjust the brightness of the picture in the Finder.
1
Press the [SET] Button to select the item that
you want to adjust.
2
Turn the [ A T ] Dial to increase or decrease the
vertical bars of the Bar Indication.
The Bar Indication is divided into 11 steps. The more
vertical bars are shown, the stronger the brightness or
colour saturation is.
Exiting the Menu
Press the [MENU] Button twice.
•These adjustments have no influence on the actual picture
recorded.
■ Adjusting the Angle of the LCD Monitor
The LCD Monitor rotates upward a maximum of 180® 0 and
downward a maximum of 90® @ from its normal vertical
position. Trying to forcefully rotate it beyond this range could
seriously damage the Movie Camera.
38
