When connecting to separately sold power amp

The navigation unit

RCA connector

Subwoofer outputs
(SWL, SWR)

Power cord

To system control terminal of the power amp
(max. 300 mA 12 V DC).

Blue/white

Rear outputs
(REAR OUTPUT)

Front outputs
(FRONT OUTPUT)

15 cm

15 cm

Engb

14

Section

02

Connecting the system
