Руководство пользователя
16. Настройка DDM
120
www.qtech.ru
-------------- ----------- --------------------- ---------
Temperature(°С) 33
70
0
70
0
Voltage(V)
7.31(A+) 5.00
0.00 5.00 0.00
Bias current(mA) 6.11(W+) 10.30
0.00
5.00 0.00
RX Power(dBM) -30.54(A-)9.00
-25.00
9.00 -25.00
TX Power(dBM) -13.01(A-)9.00
-12.00(-25.00)
9.00 -10.00(-25.00)
Пример 3:
Ethernet 21 включен в оптический модуль с DDM. Включение мониторинга трансивера на
порте, после просмотра мониторинга на оптическом модуле.
Шаг 1: Просмотр мониторинга трансивера на опическом модуле. На Еthernet 21 и
ethernet 22 не включен мониторинг трансивера, установленный интервал 30 минут.
Switch(config)#show transceiver threshold-violation interface ethernet
1/0/21-22
Ethernet 1/0/21 transceiver threshold-violation information:
Transceiver monitor is disabled. Monitor interval is set to 30
minutes.
The last threshold-violation doesn’t exist.
Ethernet 1/0/22 transceiver threshold-violation information:
Transceiver monitor is disabled. Monitor interval is set to 30
minutes.
The last threshold-violation doesn’t exist.
Шаг 2: Включение мониторинга трансивера на ethernet 21.
Switch(config)#interface ethernet 1/0/21
Switch(config-if-ethernet1/0/21)#transceiver-monitoring enable
Шаг 3: Просмотр мониторинга трансивера на оптическом модуле. В следующих
настройках, на ethernet 21 включен мониторинг трансивера, последнее нарушение
порогового значения Jan 02 11:00:50 2011, подробная информация о DDM, превышающая
пороговое значение также показана:
Switch(config-if-ethernet1/0/21)#quit
Switch(config)#show transceiver threshold-violation interface ethernet
1/0/21-22
Ethernet 1/0/21 transceiver threshold-violation information:
Transceiver monitor is enabled. Monitor interval is set to 30 minutes.
The current time is Jan 02 12:30:50 2011.
The last threshold-violation time is Jan 02 11:00:50 2011.
