17
En
Connections
English
PRE
P
ARA
T
ION
• When “VIDEO CONV.” is set to “OFF” (see page 67), be sure
to make the same type of video connections as those made for
your TV (see page 16). For example, if you connected your TV
to the VIDEO MONITOR OUT jack of this unit, connect your
other components to the VIDEO jacks.
• When “VIDEO CONV.” is set to “ON” (see page 67), the
converted video signals are output only at the MONITOR OUT
jacks. To record a source, make the same type of video
connections between each component.
• To make a digital connection to a component other than the
default component assigned to DIGITAL INPUT jack, select
the corresponding setting for “OPTICAL IN” or “COAXIAL
IN” in “I/O ASSIGNMENT” (see page 65).
• If you connect your DVD player to both the DIGITAL INPUT
(OPTICAL) and the DIGITAL INPUT (COAXIAL) jacks,
priority is given to the signals input at the DIGITAL INPUT
(COAXIAL) jack.
■ Connecting a DVD player
Connecting other components
Notes
Make sure that this unit and other
components are unplugged from the
AC wall outlets.
MONITOR
OUT
L
R
DTV/CBL DVR DVD
MD/
CD-R
OUT
(REC)
IN
(PLAY)
OUT IN
DTV/CBL DVR DVD OUT
OUT
+12V
15mA MAX.
IN
IN
MONITOR
OUT DTV/CBL DVR DVD OUT S VIDEO IN
CD
L
R
SUB
WOOFER
WO
SURROUND
CENTER
MULTI CH INPUT AUDIO
VIDEO
OUTPUT
ZONE 2
OUT
FRONT(6CH)
SB(8CH)
1 2 3 DTV/CBL
DTV/CBL MD/CD-R
OUT
DTV/CBL
DVR
DVD
DVD
OPTICAL
COAXIAL
DVD
P R P B Y P R P B Y
MONITOR OUT
COMPONENT VIDEO
HDMI
REMOTE
TRIGGER
OUT
DIGITAL INPUT
VIDEO
IN1 IN2
4
MD/CD-R
DIGITAL
OUTPUT
L
R
DVD
DVD DVD S VIDEO
AUDIO
VIDEO
1 DVD
DVD
COAXIAL
DVD
P R P B Y
COMPONENT VIDEO
HDMI DIGITAL INPUT
VIDEO
IN1
L R C V
S P R P B Y
DVD player
HDMI out
C
o
mp
one
nt
vi
de
o o
ut
S-video out
V
id
eo ou
t
Au
di
o ou
t
indicates recommended connections
indicates alternative connections
(One for the video connection,
and one for the audio connection)
Co
ax
ia
l ou
t
