A
Part 9:
Gas convertion
Your cooker can operate both Natural Gas
and LPG. You can convert by changing the
gas source and the top burner, oven and grill
injectors. The replacement procedure of the
injectors are explained below.
Call authorized Service for gas convertion.
Replacement of the top burner
injector
Take off the burner head and burner cap
before starting this procedure. Then:
1. Remove the injector inside the top burner
with a suitable bit. Later, install the new
injector by covering the injector threads
with leakage
preventing
material.
Reduced Tap Flow
Removal of the knob
1.Ignite the burner that should be
adjusted, turn the knob to the reduced
position, pull and take the knob off.
2.
With a screwdriver, make the tap
reduced flow adjustment from the
injector that is on the gas tap (only
the head is visible with the bolt shape).
It is sufficient to tight to screw
completely, in butane/propane gas.
For the natural gas, you should turn
the screw counter-clockwise once. The
normal length of a straight flame in
the reduced position should be 6 -
7mm.
If the flame is higher than the desired
position, turn the screw clockwise. If
its smaller to the opposite.
For the last control of the burning of
the cooker, bring the cooker high-
flame and reduced positions and check
whether the f l a m e i s o n o r o f f .
29
