The stages of the function selection knob for conventional ovens
5.4 Operating the ovens-controlled by two knobs
Oven heating control knob
This knob is used together with the "function
selection" knob. Select the desired stage with the
"function selection" knob. Then rotate the "oven
heating control" knob clockwise. The lannp and the
heating elennents in conjuction with the stage you
have selected will conne on line. The
tennperature in the oven shall be sensed by the
thernnostat. The thernnostat switches off the heating
elennent and the thernnostat light when the set
tennperature level is reached inside the oven. When
the tennperature falls below thernnostat connes back
on line and the thernnostat light illunninates. This way,
the set tennperature level is nnaintained throughout
the cooking period.
Function selection knob
This knob allows you to select functions and carry out
checks. The functions and their stages are explained
below. In order to operate the stages, you need to
bring the "function selection" knob
together with the"oven heating control" knob to
the desired tennperature degree and adjust the tinner
if there is. If your cooker has timer; refer to the
description of timer usage.
Burning off the protective coating process.
In order to burn off the protective coating remove
shelves and baking tray by turning your oven to 250°C
in □ position for to 30 minute periods without putting
anything into it.
You must ensure this operation is conducted in a wall
ventilated area.
Oven lamp and warning lamps light on.
The heating elements are out of
operation.___________________
□
Oven and thermostat lamp upper and
lower heating elements are on.
It provides to cook the both sides of the
meal at the same level.
□
Lamps and lower heater are on.
You can use this position, if you want to
have the bottom side of your meal cooked
better.
□
Lamps and upper heater are on. You can
use this position, if you want to have the
top side of your meal cooked better.
IF AVAILABLE
Means only the grill heater and lamps are
on.
You must bring to the heating control
knob to the maximum temperature.
□
Oven and thermostat lamp upper and
□
lower heating elements are on. It
provides to cook the both sides of
the meal at the same level.
Lamps and lower heater are on.
You can use this position, if you
want to have the bottom side of
your meal cooked better.
□
Lamps and upper heater are on.
You can use this position, if you
want to have the top side of your
meal cooked better.
IF AVAILABLE
Means only the grill heater and
lamps are on.
You must bring to the heating
control knob to the maximum
temperature.__________________
Means lamps,both grill heater and
rôtisserie function are on.
You must bring to the heating
control knob to the maximum
temperature.
