STOVE OR BOILING PANEL LOCATION
Stove or boiling panel can be used in accordance with CSN 33 200-
3 in a general environment in a room with minimum 20 mz.
Ventilation device must be provided in smaller rooms (min. 15 ma).
With regard to heat resistance, the stove or boiling panel can be
placed on any surface (pad).
- Appliance class "A", i.e. appliance that should not be connected
with flue way or another device to remove combustion products
out of the area where it is located must be installed in an area
with sufficient ventilation that has been created in accordance
with CSN 127010:1986 and CSN 127040:1986 so that harmful
substances do not accumulate in inadmissible concentrations
in such rooms (fulfilling the requirements of workplace sanitation
statute 39/78 directive 46).
CSN 06 1008 governs secure distances of walls and furniture from
the stove or boiling panel.
1.
When installing the stove or boiling panel next to the walls with
flammability level B - almost inflammable, Cl - hardly flammable,
C2 - medium flammable, C3 - easily flammable it is necessary to
keep safe distance from the appliance according to table 1. In
range of boiling plate level up to 500 mm above the boiling plate.
Safe distance specified in Table 2 must be kept under the boiling
plate level.
2.
The stove or boiling panel can be installed right next to walls with
flammability level A - inflammable.
3.
Objects made of flammable materials must not be placed neither
on the heating device nor closer than the security distance of the
device (the smallest distance of the appliance from flammable
materials is 10 mm).
4.
The appliance must be decommissioned in case the
environment changes, i.e. when working with glues, varnishes
and other volatile materials that can prompt such change.
Table 1.
flammability
level
B
Cl
C2
C3
di (mm)
20
50
100 200
Table 2.
flammability
level
B
Cl
C2
C3
di (mm)
3
5
10
20
Picture Stove location
