4.3 Operating the Ceramic hobs
The ceramic hobs are thermostatically controlled with a 6 level
commutator.
One of the stage is the "Off" position. The application field of the six
remaining stages are given in table.
Fast radiant,dual or extended type hot plates are energy regulating
type. They adjust the burner operation time of the heater continuously
between 1st to 3rd stages.
Corresponding cooking values
Hob hot indicator lights
Show which hob is operating and/or hot. Indicator lights will remain
on whenever the hob is hot. Whenever the temperature of the hob
surface falls below 64 degrees °C limit, the indicator light will go off.
Do not touch and keep children away from the
heating zones and appliance at all times.
Energy
regulator stages
1
2
3
7 stages
commutator
1
2-3
4 - 5 - 6
Application
Position to Simmering Cooking-roasting
hold hot
boiling
Dual or extended burners are energy regulating type adjusting the
operation time of the heater continuous between 1st to 3rd stages.
Dual burner can heat up at 2 different positions. Saving energy and
time can be achieved by lighting the 1st stage for small pots and the
1st and 2nd stages for large pots. By turning the burner knob clockwise,
the inner part of the burner will heat up. You can use the 1st, 2nd and
3rd stages according to the applications indicated in the table. Keep
turning the " ® •" knob in a clockwise direction starting from the 3rd
stage until a "click" sound is heard to use the interior and exterior parts
of the burner at the same time. Both stages of the burner will operate.
After the completion
of the cooking operation, set the knob to "0" position by turning it in
a counterclockwise direction.
Caution: The 2nd stage of your dual or
extended burners will not
operate by itself.
14
