ENGLISH
Charging Time and Maximum Time for
Continuous Recording ^ n 01
Battery No. Charging Time
Max. Continuous
Recording Time
Supplied 80 min. 100 min.
VW-VBD1 80 min. 100 min.
VW-VBD2 160 min. 180 min.
CGR-B/814 320 min. 420 min.
(The times shown in the above chart are approximations.)
The times listed above for your information indicate the
duration of recording performed at an ambient
temperature of 20°C and 60% relative humidity. The
charging time may be longer when you charge the
Battery at higher or lower temperature.
♦ During use and charging, the Battery becomes warm.
The Movie Camera, too, becomes warm during use.
♦ When you repeatedly stop and restart recording, the
recording time per Battery may be shorter than listed
above.
♦ If you do not use the Battery for a long time, please
read the Precautions for Storage 140).
When the Charge Lamps Flash
When the interna) temperature of the Battery or the
ambient temperature is extremely high or low, the Charge
Lamps on the AC Adaptor flash.
When the Charge Lamps flash slowly
The Battery is being charged, but charging takes longer
than normally.
When the Charge Lamps flash in groups of 2
Charging is not possible. When the temperature becomes
appropriate for charging, the Charge Lamps stop flashing
and charging starts.
Using the Charge Confirmation Marker
You can use this marker to easily distinguish between
charged and discharged Batteries.
For example, slide the knob so that the red dot (•) O's
visible after the charging is completed.
nwm
mm 100:7311
VW-VBDl 805iil lOO^inlf
VW-VBD2 160-Tjñ 180» II
CGR-B/814 320:¥ii 420»|f
(-> 140) "
[Chargel -
i?i)$p ’ ^Rí.?tmíí: ' ■ fg^TJé (•) O
-20-
