SOUNDMAX SM-SA604 3
Features
• Class ''AB'' Technology MOSFET PWM Power Supply
• Remote turn-on of the amplifier via car radio
• Continuously Variable 12dB/Octave High Pass & 12dB/Octave Low Pass Crossover
• Enhanced Bass Boost 0/12dB @50Hz
• Regulator for input sensitivity
• Bridgeable 4-/3-/2-/1-channel & Tri-mode
• Silver Plated RCA & Power, Speaker Terminal
• Soft Start & Muting
• Capsulated screw terminals of loudspeaker and power supply
• Overload, Thermal, Short Circuit Protection
• Power & Protection indicator
Precautions: Read First!
• If after reading the direction you feel uncomfortable about installing the amplifier in your car, or not equipped
or competent to do so, you should have the amplifier installed by an authorized installer. It's your car!
• Negative battery terminal must be disconnected before any electrical connections are made.
• Be sure choose a location that provides substantial ventilation for the amplifier.
• The most preferred locations would be in your car's trunk, under the front seats or on the back wall of a
truck.
• The location chosen should provide at least 2" of clearance above the amplifier for adequate ventilation.
• If the amplifier is to be mounted vertically be sure that it is in a place where adequate air will flow along the
length of its heatsink fins for cooling.
• NEVER mount the amplifier up side down, this will cause the heat to rise back into the amplifier causing
thermal shutdown or possible permanent damage.
• NEVER mount the amplifier in a location that is subject to direct sunlight or exposed to moisture.
• Be sure to mount the amplifier to a strong, solid surface which will not give way under the stress of a sudden
stop.
• Make sure that the mounting screws will not penetrate the gas tank, brake and fuel lines, wiring or other
critical parts of your car when installed.
• NEVER operate the amplifier without the proper power and ground wire 10 gauge minimum.
