SOUNDMAX SM-SA604 16
Specification
MODEL SM-SA604
Stereo /Bridged
Nominal output power (DIN 45 342, B+=14. 4V) 4 x 60W /2 x 120W at 4 0hms
Nominal output power (DIN 45 342, B+=14. 4V) 4 x 120W at 2 Ohms
OPERATION INTO 4 OHMS @ 1KHz, 1% THD 250W х 2
Loudspeaker impedance (stereo) 2-8 Ohms
Frequency response 20 - 60 000 Hz (-3 dB)
Total harmonic distortion <0.05% (1 kHz)
Stereo separation (IEC 581) >80 dB (1 kHz)
Signal to Noise Ratio (IEC A) >95 dB
Input sensitivity LOW LEVEL INPUT 0.2-5V
Input impedance LOW LEVEL INPUT 47 kOhms
Low-pass filter 40-350 Hz, 12 dB per octave
High-pass filter 80-2500 Hz, 12 dB per octave
Bass boost 0. . . 12 dB at 45 Hz
Power supply +12V (9-15V), Negative Ground
Fuse rating 25A x2
Dimensions: WxHxD 270 x 52 x 280 mm
Weight 4. 45 Kgs
NOTE : Specifications & design subject to change without notice for improvements.
The pictures have been done for reference and can be different from real units.
