Bmmug
• if
^
•
“ (->20)
2.mmmm
° (->20)
2.nmm)\^yim^mmmm
[DCIN] JB?L°
2
ilSiI^S0^S-aia}iS3t;iElie^№
[DCOUT]ffi?L°
3
S;^^^}.tLl|}g2mi'ta5AMfflm)iiiji5ij]i^(:5:}ifLioo-24ov,
b0/60Hz) ’ r/iliiiFarl^@^atffl^-Hfe^ml''^'f±i'5I^iii'l;,il
The 3 Types of Power Supplies
To try out the Movie Camera at home, we recommend
that you use the AC Adaptor Q-
1. AC Adaptor (supplied)
•To use the Movie Camera indoors.
•To charge the Battery. (-►
20)
2. Battery (supplied)
•To use the Movie Camera outdoors, and also indoors
when there is no AC mains socket nearby. (->
20)
3. Car Battery Charger (optional)
•To use the Movie Camera in a car.
Using the AC Adaptor as Power Supply
Unit
1
Connect the DC Input Cable to the
[DC IN] Socket on the Movie Camera.
Connect the other end of the cable to the
[DC OUT] Socket on the AC Adaptor.
Connect the AC Mains Cable to the AC
Adaptor and to an AC mains socket.
2
3
The AC Adaptor features automatic universal voltage
adjustment (AC 100-240 V, 50/60 Hz), therefore, there is
no need for any manual voitage adjustment for use in
other countries.
18
