Panasonic NV-VX37EN - Инструкция (Страница 116)

I t
2 , 5
TBC/
pMENU FFFFCT^
PLAY
PAUSE STOP
3^i^4
^ ITF^^ —I L QCT
ENGLISH
1 m[0 LUXON/OFF]rif1i3iS^^[ON] » ff [OLUX]
2 ig[MENU] mm) M-
• #I±iI^.;MA N MFNU- 1>A^ ■-'
3 MiIi$[ITEM]aig)e ’ jifi[IVI.SENSOR](f^
4 i^[SET] im^) m - ^ii[ON]
5 iS[MENU]iB ’ 5it±ii^mil°
mm
!|A MA,Y MPNUljAf^-RY;MSrNSOR]M^:u;orr] -
_OL!JXON/OFF;i^|^^t§FEi:[OFF; ^
t^'E^DImAXSJi.' F #Jii;i± ’ :FFi^r?[0 I JX ON/OFF
Ft^MlX;ttt:OFF;
>:üllCXSbNSÜIi h ^ P
lö'i
Using the 0 Lux Night View Function
together with the Motion-Sensor-
Controlled Recording Function in Dark
Piaces without Any Illumination
If you use the 0 Lux Night View Function together with
the Motion-Sensor-Controlled Recording Function,
recording starts automatically when the Movie Camera’s
built-in Motion Sensor detects some movement in the
picture. This combined function is convenient for easy,
unattended animal observation recordings at night,
Set the [0 LUX ON/OFF] Switch to [ON] to
make the [OLUX] Indication appear.
Press the [MENU] Button.
•The [MAIN MENU1] Menu appears.
Press the [ITEM] Button repeatedly to
select [M.SENSOR].
Press the [SET] Button to select [ON].
Press the [MENU] Button to exit the menu.
•The Motion Sensor Function Stand-by [STDBY]
Indication appears.
1
2
3
4
5
Cancelling the 0 Lux Night View Function and
Molion-Sensor-Conlrolled Recording Function during
Stand-by
Set [M.SENSOR] on the [MAIN MENU1] Menu to [OFF]
and then set the [0 LUX ON/OFF] Switch to [OFF].
Cancelling the 0 Lux Night View Function and
Motion-Sensor-Controlled Recording Function during
Recording
Press the Recording Start/Stop Button for more than
2 seconds and then set the [0 LUX ON/OFF] Switch to
[OFF].
If you use the Motion Sensor Function together with the
0 Lux Night View Function, the [MOTION SENSOR]
Indication flashes, and recording may not be possible in
some cases.
122
