22
Cleaning and maintenance
Before any maintenance or cleaning can be
carried out, you must DISCONNECT the hob
from the electricity supply.
For reasons of hygiene and safety, the
cooking zones must be kept clean. Grease
stains and spilled food generate smoke when
heated, and can even cause fire.
Never use metal wool, metal sponges or
other abrasive cleaning agents.
Never use steam or a steam cleaning
machine to clean the appliance.
The ceramic glass hob
The decorative pattern on the ceramic surface
can become scratched and marred with use,
depending upon maintenance, but does not
adversely affect performance.
Such blemishes are not covered by the
warranty and do not affect the operation of
the hob.
Immediately scrape off stains caused by food
which has boiled over using a proper ceramic
hob scraper, spilled sugar, dishes containing
sugar (jam, juice, etc.), melted plastic and
aluminium foil while the ceramic hob is still hot.
If the ceramic hob is allowed to cool it may
become damaged.
Utensils which have been in contact with the
above-mentioned melted materials must be
cleaned throughly before used again on the
ceramic-top hob unit.
Defects in the ceramic surface which can
be related to the above are not covered
by the warranty.
A dirty ceramic hob decreases the heat transfer
between cooking zones and cookware.
After use the cooking zones should be wiped
with a damp cloth with washing up liquid.
For severe soiling you can follow these steps:
1. Remove stains etc., with a proper ceramic
hob scraper.
2. Make sure that the ceramic hob has cooled
down. Use a proper ceramic cleaning agent.
3. Wipe the ceramic hob clean with a damp cloth
or kitchen roll. Tough stains can be removed
by rubbing the stain hard with kitchen roll.
4. Wipe off remaining cleaning agent with a
damp cloth.
5. Wipe with a dry cloth, if required.
Make sure that the ceramic hob is dry when you
heat it up again. Ceramic hobs can develop
rainbow-like stripes if heated while damp.
Stainless steel surfaces
Clean the appliance after use with a soft cloth
well wrung out in warm water, use a small
amount of liquid detergent for stubborn soiling.
Stainless steel parts may become straw
coloured with use, use a proprietary stainless
steel cleaner to remove this straw discolouration.
Hotplate Rating
Rear Cooking Zone Ø 180mm 1,7 kW
Front Cooking Zone Ø 145mm 1,2 kW
Total Rating 2,9 kW
Electric Supply 230 V 50 Hz
Hob recess dimensions
Length 270 mm.
Width 490 mm.
This appliance complies with the following
E.E.C. Directives:
- 73/23 - 90/683 (Low Voltage Directive);
- 89/336 (Electromagnetical Compatibility Directive);
- 93/68 (General Directives)
and subsequent modifications.
Technical Data
MANUFACTURER:
ELECTROLUX HOME PRODUCTS ITALY S.p.A.
Viale Bologna, 298 I-47100 FORLÌ (Italy)
