20
Contents
For the User
For Your Safety 26
Description of the appliance 27
How to use 27
Hints and tips 28
Cleaning and maintenance 29
For the Installer
Technical Data 29
Instruction for the Installer 30
Electrical connection 30
Building In 31
Possibilities for insertion 32
Guarantee conditions 33
Control knobs
The regulating of heat is graduation-free for both
plates on a scale from 1 to 6.
“1” Represents lowest heat
“6” Represents maximum heat.
“0” Represents “OFF”.
Description of the product
1 Rear cooking zone, 180 mm, 1700 W
2 Front cooking zone, 145 mm, 1200 W
3 Pilot lamp
4 Control knob for the rear cooking zone
5 Control knob for the front cooking zone
How To Use
Setting 1 Keeping warm
Setting 2 Gentle simmering
Setting 3 Simmering
Setting 4 Frying / browning
Setting 5 Bringing to the boil
Setting 6 Bringing to the boil / quick
frying / deep-frying
Pilot light
Pilot light is activated when either of the zones are
turned on, and will remain on until the cooking
zones are switched off.
Do not use the ceramic hob if the glass
is damaged.
If a fault or crack appears during cooking
disconnect the hob immediately and contact
Electrolux Service.
Warning:
Aluminum foil and plastic utensils are not
to be placed on hot surfaces.
The surface may not be used for storage.
Do not stare at the heating units when in
operation.
1
2
3
4
5
