28
7-1-3. Collective deletion
• All group setting information and interlocked unit setting information can be deleted.
This function is valid only when this controller is the master.
(1) Display the Group Setting Screen or Interlocked Unit Setting Screen.
(2) All set information will be deleted when the MODE switch is held down for three or more
seconds in this state.
The COLLECTIVE ON/OFF lamp flickers, and "88", "888" and
"88" flicker at the group No. display section, the operation No.
display section and operation time display section respectively.
"H0" flickers at the pattern No. display section
During collective deletion communication
process ◎
Initial state ◎
8. Setting the functions
Function setting switch
Remote controller main unit
8-1. Using with master system controller
• When connecting multiple system controllers, the system controller with many functions is
designated as the "master", and the system controller with few functions is designated as the
"slave". The "master/slave" functions of the system controller used together are as follows.
The functions have a priority in order of G-50A (MJ-103MTR-A) > PAC-SF44 SRA > PAC-YT34STA > PAC-YT40ANRA > PAC-SC30GRA > LMAP02-E.
Setting details Switch setting
Master side SW3-1: OFF
Slave side SW3-1: ON
