21
GB
7-1-1. Setting the group
• Register the indoor unit, LOSSNAY, slave system controller and local remote controller for each
group. (Register the LOSSNAY to be interlocked with the indoor unit using the interlocked unit
setting.)
1. Select the group.
2. Select the unit.
3. Registering the group into the unit
4. Searching for registered units
5. Deleting a unit from a group
Go to step 7-1(4) or 7-1-2.
1. Select the group.
(1) The group No. displayed in the group No. display will change each time the GROUP
switch is pressed.
The numbers will display in reverse when the switch is pressed.
(2) After the group is selected, if a unit is registered in the group the minimum address No. unit will
appear. The attributes for that group will appear after two seconds.
Operation No. display section ... Address No.
Pattern No. display section ... Address No. attributes
Displayed details
Example) When groups 1 and 2 are not registered, and the address 005 indoor unit is registered in group 3
Press once.
Press once.
Pattern No. display section:
"--" appears if nothing is set.
Operation No. display section:
"--" appears if nothing is set.
Initial Setting Mode
Select group 2
Select group 3
The 005 indoor unit is already registered.
