20
This controller’s own address will flicker for two seconds.
Own address display screen
Initial Setting Mode Screen (Group Setting Screen)
Carry out steps 7-1-1 to 7-1-2 from the state shown above.
(4) Cancel the initial setting mode.
• After setting the group and the interlocked unit, hold down the TEMP. and CLEAR switches
simultaneously.
• Save the group setting information and interlocked unit setting information, etc., with this step, and then
carry out system startup communication. The Group Setting/Monitor Screen will open when completed.
(Refer to step (2).)
• If no operations are made on this screen for ten minutes, the display will automatically switch to the
Normal screen.
Note that if the group setting information has not been saved, the screen will not change automatically.
NOTE Do not turn the power OFF during system startup communication (while "H1" is flickering). (The group
setting information, etc., will not be saved in the memory if the power is turned OFF.)
