6
2-3. Operation section
MONITOR/SET GROUP DAY DAY PATTERN
TIMER
ON/OFF
PROHIBIT MODE ON/OFF OPERATION PATTERN
CLOCK TEMP. CLEAR
SCHEDULE TIMER
PAC-YT34STA
1
2
5 6
4
7
3
8
9
10
1. GROUP SELECT SWITCH
Press this to call the required group screen when making various settings.
2. MONITOR/SET SWITCH
Use this switch to change between the [NORMAL SCREEN], [PROGRAM MONITOR SCREEN], [PROGRAM
SETTING SCREEN] and [WEEKLY PROGRAM SETTING SCREEN].
3. CLOCK SWITCH
Use this switch to set the current time and program time.
4. TEMP. SWITCH
Use this switch to set the schedule operation.
* ON/OFF: Select ON, OFF or no setting.
* Use this to start or stop the group independently or collectively.
* Operation changeover: Select cooling, heating or no setting.
* Set Temperature: Select set temperature or no setting.
* Prohibit: Select operation prohibit, enable or no setting.
5. DAY SWITCH
Use this switch to change the day for the [TIME/DAY SETTING] and [WEEKLY PROGRAM SETTING].
6. DAY PATTERN SWITCH
Use this switch to display the day pattern for [WEEKLY PROGRAM SETTING].
7. TIMER ON/OFF SWITCH
Use this switch to stop the schedule function for all groups currently being controlled.
8. CLEAR SWITCH
Use this switch to clear the program settings.
9. PATTERN SWITCH
Use this switch to set the schedule pattern No.
10.OPERATION SWITCH
Use this switch to set the schedule operation No.
