24
7-1-2. Setting the interlocked units
• Set that units interlocked with each group can be run in linked.
• Set the interlocked unit after setting each group.
The interlocked units cannot be set until the units are registered in the group in which interlocked
units are to be set.
1. Calling the Interlocked Unit Setting Screen
2. Selecting the group No.
3. Calling the registration unit
4. Selecting the interlocked unit's address No.
5. Registering the interlocked unit
Go to step 7-1(4) or 7-1-1.
6. Searching for interlocked units
7. Cancelling the interlock setting
Select the group to be registered as the interlocked unit.
This also applies when searching or deleting.
NOTE • When registering the interlocked unit, if an indoor unit and interlocked unit in a certain group are to be
linked, always register the indoor unit with the smallest address No. in the group for interlocking. If the
unit is not registered for interlocking, the interlocked unit cannot be operated with the local remote
controller.
• If there are several indoor units to be linked with the interlocked unit, register all indoor units for
interlocking.
1. Calling the Interlocked Unit Setting Screen
(1) Open the Interlocked Unit Setting Screen from the Group Setting Screen.
Press
the MONITOR/SET switch.
Pattern No. display section: "--" or the attributes are displayed.
Initial Setting Mode Screen (Group Setting Screen)
Interlocked Unit Setting Screen
Operation time display section:
"--" or the interlocked unit's address No. is displayed.
Operation time display section:
"---" or the unit address No. is displayed.
The screens will alternate between the Group Setting Screen and Interlocked Unit
Setting Screen each time the MONITOR/SET switch is pressed.
