ENGLISH
Insert Editing
You can record a new scene onto a previously recorded tape,
replacing a section of the original recording with minimal picture
distortion at the in- and out-points. The original audio remains
unchanged.
1
Insert the recorded cassette and set the
[CAMERA/OFF/VCR] Switch to [VCR].
• Be sure to insert the cassette with an intact tab or if the
tab has been removed, cover the hole with an adhesive
tape.
2
Press the [^] Button to start playback and
press the Pause Button [II] at the tape
position at which you want the editing to stop.
Reset the Tape Counter to zero. 122)
3
4
5
6
100
Set [DISPLAY] on the [DISPLAY SETUP]
Sub-Menu to [MEMORY].
Play back a still picture at the point at which
you want the Insert Editing to start.
Set [INSERT] on the [OTHER FUNCTIONS]
Sub-Menu to [ON].
•The [INSERT] Indication O appears.
7
Turn the Movie Camera to the title to be
inserted and press the Recording Start/Stop
Button.
•The Insert Editing automatically stops approximately at
the position at which you reset the counter to zero.
Stopping Insert Editing
Press the Recording Start/Stop Button.
The Movie Camera is again in the Recording Pause Mode.
Cancelling the Insert Editing Function
Press the [■] Button.
• It is not possible to set [INSERT] on the [OTHER
FUNCTIONS] Sub-Menu to [ON] when it is not in the Still
Playback Mode.
• It is not possible to perform Insert Editing on an unrecorded
part of the tape. If you try to do so, the tape will stop.
•When pressing the [MENU] Button in the Recording Pause
Mode, the Menu of Camera Mode appears. However, you
cannot use the [MOTION SENSOR] of the [CAMERA SETUP]
Sub-Menu, [REC SPEED] and [INTERVAL REC] of the
[OTHER FUNCTIONS] Sub-Menu.
