tfi S;
1 M-M8.20)
3 (ffiPSi^NV-VZ14A/Z15)
iS]^siii[AOPENHf ’
f^SmgSÍTI8^90"»
ENGLISH
;es ■ att •
4 EJECT] (S^ttl)ffl °
5 mxmm^ • »
6 mrmm^mm. ■ ^««[ lock ]® °
• ■ [^]igAS§FAW»
s a t '
» m m
■ °
“ h ""
Inserting/Ejecting the Cassette
1 Connect the AC Adaptor or attach a charged
Battery. (-♦ 18,20)
2 Turn the cog wheel O tighten the tape.
(NV-VZ14A/Z15 only)
Slide the [ AOPEN] Lever to the left and
simultaneously open the LCD Monitor in the
direction of the arrow approximately 90^.
•Be sure to keep the LCD Monitor in its vertical position,
so that the Cassette Compartment Cover, when it opens,
does not hit the LCD Monitor.
Press the EJECT] Button.
Insert the cassette with the cassette window
0 facing outward and push it all the way in.
Close the Cassette Compartment by pressing
the [LOCK] Button.
4
5
• If the AC Adaptor or Battery is used to supply power, it is
possible to insert or eject the cassette without turning on the
Movie Camera.
• If a cassette with broken out erasure prevention tab is
inserted, the [l^] Indication flashes.
•You will hear noise of tightening the tape when you insert the
cassette, and noise of rewinding the tape when you close the
cassette compartment. However, this is not a malfunction.
■ Preventing Accidental Erasure of Recordings
• Recording on a previously recorded cassette erases the
existing scenes and sound.
•To protect iitiportant recordings against accidental erasure,
use a screwdriver to break out the tab © on the cassette
(some cassettes have sliding-type tabs).
•To be able to record again on a protected cassette, firmly
cover the hole where the tab was with two layers of adhesive
tape ©.
