ENGLISH
Watching Playback on a TV
By connecting the Movie Camera to a TV, you can watch
playback of the recorded scenes on the TV screen.
Before connecting, turn off both the Movie Camera and the TV
for safety’s sake.
1 Use the AV Cable (purchase separately) to
connect the Movie Camera with the TV.
“ i ( - > 4 0 )
1 )l# [CAMERA/OFFA/CR] MBIIgSft [OFF] °
AT ■ ■ ■
n ’ =
(ffiPii^NV-VZ14/VZ15)
aifflliitijiiit -
HH/Ym
After Use
H Take out the cassette. (-» 40)
2. Set the [CAMERA/OFF/VCR] Switch to [OFF].
S Disconnect the AC Adaptor or remove the
Battery.
Cleaning the Finder
If dust has entered the Finder...
^ Push the Buttons on both sides of the Finder
and remove it in the direction of the arrow.
^ Remove dust with a biower brush
(not suppiied).
• If you use a cotton swab or similar to clean the inside of
the Finder, use it very carefully to prevent scratching the
screen inside the Finder.
® To re-attach the Finder, push it forward onto
the Finder Tube untii it iocks with a ciick.
Cleaning the LCD Monitor
(NV-VZ14/VZ15 only)
Clean the LCD Monitor with a soft cloth or a blower brush.
Cleaning the Movie Camera Body
Wipe it with a soft cloth.
Cieaning the Lens
Clean the lens with a soft cloth or a blower brush.
